DS26519 16-Port T1/E1/J1 Transceiver
123 of 310
ADDR NAME BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0
0C5h RCBR2 CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9
0C6h RCBR3 CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17
— — — — — — — —
0C7h RCBR4
CH32 CH31 CH30 CH29 CH28 CH27 CH26 CH25(F-bit)
0C8h RSI1 CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
0C9h RSI2 CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9
0CAh RSI3 CH24 CH23 CH22 CH21 CH200 CH19 CH18 CH17
— — — — — — — —
0CBh RSI4
CH32 CH31 CH30 CH29 CH28 CH27 CH26 CH25
0CCh RGCCS1 CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
0CDh RGCCS2 CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9
0CEh RGCCS3 CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17
— — — — — — — —
0CFh RGCCS4
CH32 CH31 CH30 CH29 CH28 CH27 CH26 CH25(F-bit)
0D0h RCICE1 CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
0D1h RCICE2 CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9
0D2h RCICE3 CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17
— — — — — — — —
0D3h RCICE4
CH32 CH31 CH30 CH29 CH28 CH27 CH26 CH25
0D4h RBPCS1 CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
0D5h RBPCS2 CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9
0D6h RBPCS3 CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17
— — — — — — — —
0D7h RBPCS4
CH32 CH31 CH30 CH29 CH28 CH27 CH26 CH25
100h TDMWE1 CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
101h TDMWE2 CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9
102h TDMWE3 CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17
103h TDMWE4 CH32 CH31 CH30 CH29 CH28 CH27 CH26 CH25
104h TJBE1 CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
105h TJBE2 CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9
106h TJBE3 CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17
107h TJBE4 CH32 CH31 CH30 CH29 CH28 CH27 CH26 CH25
108h TDDS1 CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
109h TDDS2 CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9
10Ah TDDS3 CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17
110h THC1 NOFS TEOML THR THMS TFS TEOM TZSD TCRCD
111h THBSE TBSE8 TBSE7 TBSE6 TBSE5 TBSE4 TBSE3 TBSE2 TBSE1
TABT SBOC THCEN THCS4 THCS3 THCS2 THCS1 THCS0
113h THC2
TABT — THCEN THCS4 THCS3 THCS2 THCS1 THCS0
118h SSIE1 CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
119h SSIE2 CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9
11Ah SSIE3 CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17
— — — — — — — —
11Bh SSIE4
CH32 CH31 CH30 CH29 CH28 CH27 CH26 CH25
120h TIDR1 C7 C6 C5 C4 C3 C2 C1 C0
121h TIDR2 C7 C6 C5 C4 C3 C2 C1 C0
122h TIDR3 C7 C6 C5 C4 C3 C2 C1 C0
123h TIDR4 C7 C6 C5 C4 C3 C2 C1 C0
124h TIDR5 C7 C6 C5 C4 C3 C2 C1 C0
125h TIDR6 C7 C6 C5 C4 C3 C2 C1 C0
