DS26519 16-Port T1/E1/J1 Transceiver
235 of 310
Register Name: TCR4
Register Description: Transmit Control Register 4
Register Address: 186h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name uALAW BINV1 BINV0 TJBEN TRAIM TAISM TC1 TC0
uALAW BINV1 BINV0 TJBEN — — — —
Default 0 0 0 0 0 0 0 0
Bit 7: u-Law or A-Law Digital Milliwatt Code Select (uALAW)
0 = u-law code is inserted based on TDMWEx registers.
1 = A-law code is inserted based on TDMWEx registers.
Bits 6 and 5: Transmit Bit Inversion (BINV[1:0])
00 = No inversion.
01 = Invert framing.
10 = Invert signaling.
11 = Invert payload.
Bit 4: Transmit Jammed Bit 8 Suppression Enable (TJBEN)
0 = No stuffing enabled.
1 = Jammed Bit 8 Suppression enabled. This forces bit 8 to a one as determined by
TJBE1 –4 registers
and bit 7 to a one in T1 signaling frames.
Bits 3: Transmit RAI Mode (TRAIM) (T1 Mode Only). Determines the pattern sent when TRAI (
TCR1 .0) is
activated in ESF frame mode only.
0 = Transmit normal RAI when TCR1 .RAI = 1
1 = If T1 ESF mode, transmit RAI-CI (T1.403) when TCR1 .RAI = 1
Bits 2 : Transmit AIS Mode (TAISM) (T1 Mode Only). Determines the pattern sent when TAIS (
TCR1 .1) is
activated.
0 = Transmit normal AIS (unframed all ones) upon activation with TCR1 .1.
1 = Transmit AIS-CI (T1.403) upon activation with TCR1 .1.
Bits 1 and 0 : Transmit Code Length Definition Bits (TC[1:0]) (T1 Mode Only)
TC1 TC0 Length Selected
0 0 5 bits
0 1 6 bits : 3 bits
1 0 7 bits
1 1 16 bits : 8 bits : 4 bits : 2 bits : 1 bit
