DS26519 16-Port T1/E1/J1 Transceiver
106 of 310
9.13 Bit Error-Rate Test Function (BERT)
The BERT (Bit Error Rate Tester) block can generate and detect both pseudorandom and repeating bit patterns. It
is used to test and stress data-communication links. BERT functionality is dedicated for each of the transceivers.
The registers related to the configure, control, and status of the BERT are shown in
Table 9-44 .
Table 9-44. Registers Related to Configure, Control, and Status of BERT
REGISTER
FRAMER 1
ADDRESSES
FUNCTION
Global BERT Interrupt Status
Register 1 (
GBISR1 )
00FAh
Global BERT Interrupt Status
Register 2 (
GBISR2 )
20FAh
When any of the 16 BERTs issue an interrupt, a bit
will be set.
Global BERT Interrupt Mask Register
1 (
GBIMR1 )
00FDh
Global BERT Interrupt Mask Register
2 (
GBIMR2 )
20FDh
When any of the 16 BERTs issue an interrupt, a bit
will be set.
Receive Expansion Port Control
Register (
RXPC )
08Ah Enable for the receiver BERT.
Receive BERT Port Bit Suppress
Register (
RBPBS )
08Bh Bit suppression for the receive BERT.
Receive BERT Port Channel Select
Registers 1 to 4 (
RBPCS1 -4)
0D4h, 0D5h, 0D6h,
0D7h
Channels to be enabled for the framer to accept
data from the BERT pattern generator.
Transmit Expansion Port Control
Register (
TXPC )
18Ah Enable for the transmitter BERT.
Transmit BERT Port Bit Suppress
Register (
TBPBS )
18Bh Bit suppression for the transmit BERT.
Transmit BERT Port Channel Select
Registers 1 to 4 (
TBPCS1 -4)
1D4h, 1D5h, 1D6h,
1D7h
Channels to be enabled for the framer to accept
data from the transmit BERT pattern generator.
BERT Alternating Word Count Rate
Register (
BAWC )
1100h BERT alternating pattern count register.
BERT Repetitive Pattern Set Register
1 (
BRP1 )
1101h BERT repetitive pattern set register 1.
BERT Repetitive Pattern Set Register
2 (
BRP2 )
1102h BERT repetitive pattern set register 2.
BERT Repetitive Pattern Set Register
3 (
BRP3 )
1103h BERT repetitive pattern set register 3.
BERT Repetitive Pattern Set Register
4 (
BRP4 )
1104h BERT repetitive pattern set register 4.
BERT Control Register 1 ( BC1 ) 1105h Pattern selection and miscellaneous control.
BERT Control Register 2 ( BC2 ) 1106h BERT bit pattern length control
BERT Bit Count Register 1 ( BBC1 ) 1107h Increments for BERT bit clocks.
BERT Bit Count Register 2 ( BBC2 ) 1108h BERT bit counter.
BERT Bit Count Register 3 ( BBC3 ) 1109h BERT bit counter.
BERT Bit Count Register 4 ( BBC4 ) 110Ah BERT bit counter.
BERT Error Count Register 1 ( BEC1 ) 110Bh BERT error counter.
BERT Error Count Register 2 ( BEC2 ) 110Ch BERT error counter.
BERT Error Count Register 3 ( BEC3 ) 110Dh BERT error counter.
BERT Latched Status Register
(
BLSR )
110Eh Denotes synchronization loss and other status.
BERT Status Interrupt Mask Register
(
BSIM )
110Fh BERT interrupt mask.
Note: The addresses shown above are for Framer 1.
