Register Name: E1TSACR
Register Description: E1 Transmit Sa-Bit Control Register
Register Address: 114h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name SiAF SiNAF RA Sa4 Sa5 Sa6 Sa7 Sa8
Default 0 0 0 0 0 0 0 0
Bit 7: International Bit in Align Frame Insertion Control Bit (SiAF)
0 = Do not insert data from the E1TSiAF register into the transmit data stream.
1 = Insert data from the E1TSiAF register into the transmit data stream.
Bit 6: International Bit in Non-Align Frame Insertion Control Bit (SiNAF)
0 = Do not insert data from the E1TSiNAF register into the transmit data stream.
1 = Insert data from the E1TSiNAF register into the transmit data stream.
Bit 5: Remote Alarm Insertion Control Bit (RA)
0 = Do not insert data from the E1TRA register into the transmit data stream.
1 = Insert data from the E1TRA register into the transmit data stream.
Bit 4: Additional Bit 4 Insertion Control Bit (Sa4)
0 = Do not insert data from the E1TSa4 register into the transmit data stream.
1 = Insert data from the E1TSa4 register into the transmit data stream.
Bit 3: Additional Bit 5 Insertion Control Bit (Sa5)
0 = Do not insert data from the E1TSa5 register into the transmit data stream.
1 = Insert data from the E1TSa5 register into the transmit data stream.
Bit 2: Additional Bit 6 Insertion Control Bit (Sa6)
0 = Do not insert data from the E1TSa6 register into the transmit data stream.
1 = Insert data from the E1TSa6 register into the transmit data stream.
Bit 1: Additional Bit 7 Insertion Control Bit (Sa7)
0 = Do not insert data from the E1TSa7 register into the transmit data stream.
1 = Insert data from the E1TSa7 register into the transmit data stream.
Bit 0: Additional Bit 8 Insertion Control Bit (Sa8)
0 = Do not insert data from the E1TSa8 register into the transmit data stream.
1 = Insert data from the E1TSa8 register into the transmit data stream.
