DS26519 16-Port T1/E1/J1 Transceiver
119 of 310
10.2.2 Framer Register Bit Map
Table 10-8 contains the framer registers of the DS26519. Some registers have dual functionality based on the
selection of T1/J1 or E1 operating mode in the RMMR and TMMR registers. These dual-function registers are
shown below using two lines of text. The first line of text is the bit functionality for T1/J1 mode. The second line is
the bit functionality in E1 mode, in italics. Bits that are not used for an operating mode are denoted with a single
dash “—“. When there is only one set of bit definitions listed for a register, the bit functionality does not change with
respect to the selection of T1/J1 or E1 mode. All registers not listed are reserved and should be initialized with a
value of 00h for proper operation. The addresses shown are for Framer 1. Addresses for Framers 2 to 16 can be
calculated using the following formula: Address for Framer n = (Framer 1 address + (n - 1) x 200hex).
Table 10-8. Framer Register Bit Map
ADDR NAME BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0
000h E1RDMWE1 CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
001h E1RDMWE2 CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9
002h E1RDMWE3 CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17
003h E1RDMWE4 CH32 CH31 CH30 CH29 CH28 CH27 CH26 CH25
010h RHC RCRCD RHR RHMS RHCS4 RHCS3 RHCS2 RHCS1 RHCS0
011h RHBSE BSE8 BSE7 BSE6 BSE5 BSE4 BSE3 BSE2 BSE1
012h RDS0SEL — — — RCM4 RCM3 RCM2 RCM1 RCM0
— — — RFSA1 — RSFF RSFE RSIE
013h RSIGC
— — — CASMS — RSFF RSFE RSEI
T1RCR2 — — — RSLC96 OOF2 OOF1 RAIIE RRAIS
014h
E1RSAIMR — — — RSa4IM RSa5IM RSa6IM RSa7IM RSa8IM
015h T1RBOCC RBR — RBD1 RBD0 — RBF1 RBF0 —
020h RIDR1 C7 C6 C5 C4 C3 C2 C1 C0
021h RIDR2 C7 C6 C5 C4 C3 C2 C1 C0
022h RIDR3 C7 C6 C5 C4 C3 C2 C1 C0
023h RIDR4 C7 C6 C5 C4 C3 C2 C1 C0
024h RIDR5 C7 C6 C5 C4 C3 C2 C1 C0
025h RIDR6 C7 C6 C5 C4 C3 C2 C1 C0
026h RIDR7 C7 C6 C5 C4 C3 C2 C1 C0
027h RIDR8 C7 C6 C5 C4 C3 C2 C1 C0
028h RIDR9 C7 C6 C5 C4 C3 C2 C1 C0
029h RIDR10 C7 C6 C5 C4 C3 C2 C1 C0
02Ah RIDR11 C7 C6 C5 C4 C3 C2 C1 C0
02Bh RIDR12 C7 C6 C5 C4 C3 C2 C1 C0
02Ch RIDR13 C7 C6 C5 C4 C3 C2 C1 C0
02Dh RIDR14 C7 C6 C5 C4 C3 C2 C1 C0
02Eh RIDR15 C7 C6 C5 C4 C3 C2 C1 C0
02Fh RIDR16 C7 C6 C5 C4 C3 C2 C1 C0
030h RIDR17 C7 C6 C5 C4 C3 C2 C1 C0
031h RIDR18 C7 C6 C5 C4 C3 C2 C1 C0
032h RIDR19 C7 C6 C5 C4 C3 C2 C1 C0
033h RIDR20 C7 C6 C5 C4 C3 C2 C1 C0
034h RIDR21 C7 C6 C5 C4 C3 C2 C1 C0
035h RIDR22 C7 C6 C5 C4 C3 C2 C1 C0
036h RIDR23 C7 C6 C5 C4 C3 C2 C1 C0
037h RIDR24 C7 C6 C5 C4 C3 C2 C1 C0
T1RSAOI1 CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
038h
RIDR25 C7 C6 C5 C4 C3 C2 C1 C0
T1RSAOI2 CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9
039h
RIDR26 C7 C6 C5 C4 C3 C2 C1 C0
