DS26519 16-Port T1/E1/J1 Transceiver
172 of 310
Register Name: E1RSiNAF (E1 Mode Only)
Register Description: Receive Si Bits of the Non-Align Frame Register
Register Address: 067h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name SiF15 SiF13 SiF11 SiF9 SiF7 SiF5 SiF3 SiF1
Default 0 0 0 0 0 0 0 0
Bit 7: Si Bit of Frame 15 (SiF15)
Bit 6: Si Bit of Frame 13 (SiF13)
Bit 5: Si Bit of Frame 11 (SiF11)
Bit 4: Si Bit of Frame 9 (SiF9)
Bit 3: Si Bit of Frame 7 (SiF7)
Bit 2: Si Bit of Frame 5 (SiF5)
Bit 1: Si Bit of Frame 3 (SiF3)
Bit 0: Si Bit of Frame 1 (SiF1)
Register Name: E1RRA (E1 Mode Only)
Register Description: Receive Remote Alarm Register
Register Address: 068h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name RRAF15 RRAF13 RRAF11 RRAF9 RRAF7 RRAF5 RRAF3 RRAF1
Default 0 0 0 0 0 0 0 0
Bit 7: Remote Alarm Bit of Frame 15 (RRAF15)
Bit 6: Remote Alarm Bit of Frame 13 (RRAF13)
Bit 5: Remote Alarm Bit of Frame 11 (RRAF11)
Bit 4: Remote Alarm Bit of Frame 9 (RRAF9)
Bit 3: Remote Alarm Bit of Frame 7 (RRAF7)
Bit 2: Remote Alarm Bit of Frame 5 (RRAF5)
Bit 1: Remote Alarm Bit of Frame 3 (RRAF3)
Bit 0: Remote Alarm Bit of Frame 1 (RRAF1)
