DS26519 16-Port T1/E1/J1 Transceiver
199 of 310
Register Name: RIM3 (T1 Mode)
Register Description: Receive Interrupt Mask Register 3
Register Address: 0A2h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name LORCC LSPC LDNC LUPC LORCD LSPD LDND LUPD
Default
0 0 0 0 0 0 0 0
Note: See RIM3 for E1 Mode.
Bit 7: Loss of Receive Clock Condition Clear (LORCC)
0 = Interrupt masked.
1 = Interrupt enabled.
Bit 6: Spare Code Detected Condition Clear (LSPC)
0 = Interrupt masked.
1 = Interrupt enabled.
Bit 5: Loop Down Code Detected Condition Clear (LDNC)
0 = Interrupt masked.
1 = Interrupt enabled.
Bit 4: Loop Up Code Detected Condition Clear (LUPC)
0 = Interrupt masked.
1 = Interrupt enabled.
Bit 3: Loss of Receive Clock Condition Detect (LORCD)
0 = Interrupt masked
1 = Interrupt enabled
Bit 2: Spare Code Detected Condition Detect (LSPD)
0 = Interrupt masked.
1 = Interrupt enabled.
Bit 1 : Loop Down Code Detected Condition Detect (LDND)
0 = Interrupt masked.
1 = Interrupt enabled.
Bit 0: Loop Up Code Detected Condition Detect (LUPD)
0 = Interrupt masked.
1 = Interrupt enabled.
