DS26519 16-Port T1/E1/J1 Transceiver
29 of 310
NAME PIN
TYPE
FUNCTION
MICROPROCESSOR INTERFACE
A13 C16
A12 F12
A11 A20
A10 G11
A9 H9
A8 A21
A7 F13
A6 A22
A5 H10
A4 B19
A3 H11
A2 D15
A1 G13
A0 B20
Input
Address [13:0].
This bus selects a specific register in the DS26519 during
read/write access. A13 is the MSB and A0 is the LSB.
D[7]/
SPI_CPOL
Y9 Input
Data [7]/SPI Interface Clock Polarity
D[7]:
Bit 7 of the 16-bit or 8-bit data bus used to input data during register writes
and data outputs during register reads. Not driven when
CSB = 1.
SPI_CPOL:
This signal selects the clock polarity when SPI_SEL = 1. See Section
for detailed timing and functionality information. Default setting is low.
D[6]/
SPI_CPHA
U8 Input
Data [6]/SPI Interface Clock Phase
D[6]:
Bit 6 of the 16-bit or 8-bit data bus used to input data during register writes
and data outputs during register reads. Not driven when
CSB = 1.
SPI_CPHA:
This signal selects the clock phase when SPI_SEL = 1. See Section
for detailed timing and functionality information. Default setting is low.
D[5]/
SPI_SWAP
AA6 Input
Data [5]/SPI Bit Order Swap
D[5]:
Bit 5 of the 16-bit or 8-bit data bus used to input data during register writes
and data outputs during register reads. Not driven when
CSB = 1.
SPI_SWAP:
This signal is active when SPI_SEL = 1. The address and data bit
order is swapped when SPI_SWAP is high. The R/W and B bit positions are
never changed in the control word.
0 = LSB is transmitted and received first.
1 = MSB is transmitted and received first.
D[4] T14
Input
Data [4].
Bit 4 of the 8-bit data bus used to input data during register writes and
data outputs during register reads. Not driven when
CSB = 1.
D[3] AB5
Input
Data [3].
Bit 3 of the 8-bit data bus used to input data during register writes and
data outputs during register reads. Not driven when
CSB = 1.
D[2]/
SPI_SCLK
R14 Input
Data [2]/SPI Serial Interface Clock
D[2]:
Bit 2 of the 8-bit data bus used to input data during register writes and data
outputs during register reads. Not driven when
CSB = 1.
SPI_SCLK:
SPI Serial Clock Input when SPI_SEL = 1.
D[1]/
SPI_MOSI
AA5 Input
Data [1]/SPI Serial Interface Data Master Out-Slave In
D[1]
: Bit 1 of the 8-bit data bus used to input data during register writes, and data
outputs during register reads. Not driven when
CSB = 1.
SPI_MOSI:
SPI Serial Data Input (Master Out-Slave In) when SPI_SEL = 1.
D[0]/
SPI_MISO
P14 Input
Data [0]/SPI Serial Interface Data Master In-Slave Out
D[0]:
Bit 0 of the 8-bit data bus used to input data during register writes and data
outputs during register reads. Not driven when
CSB = 1.
SPI_MISO:
SPI Serial Data Output (Master In-Slave Out) when SPI_SEL = 1.
CSB
W8 I
Chip-Select Bar.
This active-low signal is used to qualify register read/write
accesses. The
RDB/DSB and WRB signals are qualified with CSB.
RDB/
DSB
Y8 I
Read-Data Bar/Data-Strobe Bar.
This active-low signal along with
CSB qualifies
read access to one of the DS26519 registers. The DS26519 drives the data bus
with the contents of the addressed register while
RDB and CSB are low.
