DS26519 16-Port T1/E1/J1 Transceiver
164 of 310
Register Name:
LCVCR1
Register Description:
Line Code Violation Count Register 1
Register Address:
050h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name LCVC15
LCVC14
LCVC13
LCVC12 LCVC11 LCVC10 LCVC9 LCVC8
Default
0 0 0 0 0 0 0 0
Bits 7 to 0: Line Code Violation Counter Bits 15 to 8 (LCVC[15:8]). LCV15 is the MSB of the 16-bit code
violation count.
Register Name:
LCVCR2
Register Description:
Line Code Violation Count Register 2
Register Address:
051h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name LCVC7 LCVC6 LCVC5 LCVC4 LCVC3 LCVC2 LCVC1 LCVC0
Default
0 0 0 0 0 0 0 0
Bits 7 to 0: Line Code Violation Counter Bits 7 to 0 (LCVC[7:0]). LCV0 is the LSB of the 16-bit code violation
count.
Register Name:
PCVCR1
Register Description:
Path Code Violation Count Register 1
Register Address:
052h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name PCVC15
PCVC14
PCVC13 PCVC12 PCVC11 PCVC10 PCVC9 PCVC8
Default
0 0 0 0 0 0 0 0
Bits 7 to 0: Path Code Violation Counter Bits 15 to 8 (PCVC[15:8]). PCVC15 is the MSB of the 16-bit path code
violation count.
Register Name:
PCVCR2
Register Description:
Path Code Violation Count Register 2
Register Address:
053h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name PCVC7 PCVC6 PCVC5
PCVC4 PCVC3 PCVC2 PCVC1 PCVC0
Default
0 0 0 0 0 0 0 0
Bits 7 to 0: Path Code Violation Counter Bits 7 to 0 (PCVC[7:0]). PCVC0 is the LSB of the 16-bit path code
violation count.
