DS26519 16-Port T1/E1/J1 Transceiver
209 of 310
Register Name: RRTS5
Register Description: Receive Real-Time Status Register 5 (HDLC)
Register Address: 0B4h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name — PS2 PS1 PS0 — — RHWM RNE
Default 0 0 0 0 0 0 0 0
Note: All bits in this register are real time.
Bits 6 to 4: Receive Packet Status (PS[2:0]). These are real-time bits indicating the status as of the last read of
the receive FIFO.
PS2 PS1 PS0 PACKET STATUS
0 0 0 In Progress: End of message has not yet been reached.
0 0 1 Packet OK: Packet ended with correct CRC codeword.
0 1 0 CRC Error: A closing flag was detected, preceded by a corrupt CRC codeword.
0 1 1 Abort: Packet ended because an abort signal was detected (7 or more ones in a row).
1 0 0 Overrun: HDLC controller terminated reception of packet because receive FIFO is full.
Bit 1: Receive FIFO Above High Watermark Condition (RHWM). Set when the receive 64-byte FIFO fills beyond
the high watermark as defined by the Receive HDLC FIFO Control Register (RHFC). This is a real-time bit.
Bit 0: Receive FIFO Not Empty Condition (RNE). Set when the receive 64-byte FIFO has at least one byte
available for a read. This is a real-time bit.
Register Name: RHPBA
Register Description: Receive HDLC Packet Bytes Available Register
Register Address: 0B5h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name MS RPBA6 RPBA5 RPBA4 RPBA3 RPBA2 RPBA1 RPBA0
Default 0 0 0 0 0 0 0 0
Bit 7: Message Status (MS)
0 = Bytes indicated by RPBA0 through RPBA6 are the end of a message. Host must check the HDLC
Status register for details.
1 = Bytes indicated by RPBA0 through RPBA6 are the beginning or continuation of a message. The host
does not need to check the HDLC Status. The MS bit will return to a value of ‘1’ when the Rx HDLC FIFO
is empty.
Bits 6 to 0: Receive FIFO Packet Bytes Available Count (RPBA[6:0]). RPBA0 is the LSB.
