DS26519 16-Port T1/E1/J1 Transceiver
31 of 310
NAME PIN TYPE FUNCTION
POWER SUPPLIES
ATVDD1 C4
ATVDD2 T1
ATVDD3 T3
ATVDD4 AA2
ATVDD5 AA21
ATVDD6 H21
ATVDD7 E21
ATVDD8 C20
ATVDD9 AB11
ATVDD10 Y15
ATVDD11 AA19
ATVDD12 K21
ATVDD13 B11
ATVDD14 A8
ATVDD15 B7
ATVDD16 L1
—
3.3V
±5% Analog Transmit Power Supply. These V
DD
inputs are used for the
transmit LIU sections of the DS26519.
ATVSS1 B3
ATVSS2 R3
ATVSS3 W1
ATVSS4 Y3
ATVSS5 Y20
ATVSS6 G22
ATVSS7 H20
ATVSS8 B22
ATVSS9 AA12
ATVSS10 Y14
ATVSS11 Y16
ATVSS12 L21
ATVSS13 B12
ATVSS14 C8
ATVSS15 A5
ATVSS16 M2
— Analog Transmit V
SS
. These pins are used for transmit analog V
SS
.
ARVDD1 C6
ARVDD2 P3
ARVDD3 U2
ARVDD4 U3
ARVDD5 Y17
ARVDD6 K22
ARVDD7 F20
ARVDD8 E22
ARVDD9 AB14
ARVDD10 AB16
ARVDD11 AA17
ARVDD12 M21
ARVDD13 B10
ARVDD14 C9
ARVDD15 B5
ARVDD16 P1
—
3.3V
±5% Analog Receive Power Supply. These V
DD
inputs are used for the
receive LIU sections of the DS26519.
