DS26519 16-Port T1/E1/J1 Transceiver

286 of 310

Figure 11-30. E1 G.802 Timing






























1

2

3

4

5

6

7

8

9

10 11 12 13 14 15 16 1718 19 20 21 22 23 24 25 26 27 28

29

30

31

0

31

32

TS#

RSYNCn

TSYNCn

RCHCLKn

TCHCLKn

RCHBLKn

TCHBLKn

CHANNEL 26

CHANNEL 25

LSB MSB

RCLKn/RSYSCLKn

TCLKn/TSYSCLKn

RSERn/TSERn

RCHCLKn/TCHCLKn

RCHBLKn/TCHBLKn

1

2

0

NOTE: RCHBLKn OR TCHBLKn PROGRAMMED TO PULSE HIGH DURING TIME SLOTS 1 THROUGH 15, 17
THROUGH 25, AND BIT 1 OF TIME SLOT 26.

Figure 11-31. E1 Transmit-Side TCHCLKn Gapped Mode During Channel 1

TCLKn

TSYNCn

TCHCLKn

TSERn

LSB

MSB
