DS26519 16-Port T1/E1/J1 Transceiver
217 of 310
Register Name:
SSIE1, SSIE2, SSIE3, SSIE4
Register Description: Software-Signaling Insertion Enable Registers 1 to 4
Register Address: 118h, 119h, 11Ah, 11Bh + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
(MSB)
(LSB)
Bit # 7 6 5 4 3 2 1 0
Name CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1 SSIE1
CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9 SSIE2
CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17 SSIE3
CH32 CH31 CH30 CH29 CH28 CH27 CH26 CH25
SSIE4 (E1
Mode Only)
Bits 7 to 0: Software-Signaling Insertion Enable for Channels 1 to 32 (CH[1:32]). These bits determine which
channels are to have signaling inserted form the Transmit Signaling registers.
0 = Do not source signaling data from the TS registers for this channel.
1 = Source signaling data from the TS registers for this channel.
Register Name: TIDR1 to TIDR32
Register Description: Transmit Idle Code Definition Registers 1 to 32
Register Address: 120h to 13Fh + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name C7 C6 C5 C4 C3 C2 C1 C0
Default 0 0 0 0 0 0 0 0
Bits 7 to 0: Per-Channel Idle Code Bits (C[7:0]). C0 is the LSB of the code (this bit is transmitted last). Address
120h is for channel 1, address 13Fh is for channel 32. TIDR25:TIDR32 are E1 mode.
