DS26519 16-Port T1/E1/J1 Transceiver
126 of 310
ADDR NAME BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0
T1.TCR2
(T1)
TFDLS TSLC96 TDDSEN FBCT2 FBCT1 TRAIS — TB7ZS
182h
E1.TCR2
(E1)
AEBE AAIS ARA — — — — —
— — TCSS1 TCSS0 MFRS TFM IBPV TLOOP
183h TCR3
— — TCSS1 TCSS0 MFRS — IBPV CRC4R
TCLKINV TSYNCINV TSSYNCINV TSCLKM TSSM TSIO TSDW TSM
184h TIOCR
TCLKINV TSYNCINV TSSYNCINV TSCLKM TSSM TSIO — TSM
185h TESCR TDATFMT TGCLKEN —— TSZS TESALGN TESR TESMDM TESE
uALAW BINV1 BINV0 TJBEN TRAIM TAISM TC1 TC0
186h TCR4
uALAW BINV1 BINV0 TJBEN — — — —
187h THFC — — — — — — TFLWM1 TFLWM0
188h TIBOC — — — IBOSEL IBOEN — — —
189h TDS0SEL — — — TCM4 TCM3 TCM2 TCM1 TCM0
18Ah TXPC — — — — — TBPDIR TBPFUS TBPEN
18Bh TBPBS BPBSE8 BPBSE7 BPBSE6 BPBSE5 BPBSE4 BPBSE3 BPBSE2 BPBSE1
— — — — — TSEN SYNCE RESYNC
18Eh TSYNCC
— — — — CRC4 TSEN SYNCE RESYNC
TESF TESEM TSLIP TSLC96 — TMF LOTCC LOTC
190h TLS1
TESF TESEM TSLIP — TAF TMF LOTCC LOTC
— — — TFDLE TUDR TMEND TLWMS TNFS
191h TLS2
— — — — TUDR TMEND TLWMS TNFS
192h TLS3 — — — — — — LOF LOFD
19Fh TIIR — — — — — TLS3 TLS2 TLS1
TESF TESEM TSLIP TSLC96 — TMF LOTCC LOTC
1A0h TIM1
TESF TESEM TSLIP — TAF TMF LOTCC LOTC
— — — TFDLE TUDR TMEND TLWMS TNFS
1A1h TIM2
— — — — TUDR TMEND TLWMS TNFS
1A2h TIM3 — — — — — — — LOFD
C7 C6 C5 C4 C3 C2 C1 C0
1ACh T1TCD1
— — — — — — — —
C7 C6 C5 C4 C3 C2 C1 C0
ADh T1TCD2
— — — — — — — —
1B1h TRTS2 — — — — TEMPTY TFULL TLWM TNF
1B3h TFBA —— TFBA6 TFBA5 TFBA4 TFBA3 TFBA2 TFBA1 TFBA0
1B4h THF THD7 THD6 THD5 THD4 THD3 THD2 THD1 THD0
1BBh TDS0M B1 B2 B3 B4 B5 B6 B7 B8
1C0h TBCS1 CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
1C1h TBCS2 CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9
1C2h TBCS3 CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17
— — — — — — — —
1C3h TBCS4
CH32 CH31 CH30 CH29 CH28 CH27 CH26 CH25
1C4h TCBR1 CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
1C5h TCBR2 CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9
1C6h TCBR3 CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17
— — — — — — — —
1C7h TCBR4
CH32 CH31 CH30 CH29 CH28 CH27 CH26 CH25:Fbit
1C8h THSCS1 CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
1C9h THSCS2 CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9
