DS26519 16-Port T1/E1/J1 Transceiver
282 of 310
11.4 E1 Transmitter Functional Timing Diagrams
Figure 11-24. E1 Transmit-Side Timing
1
2
3
4
5
6
7
8
9 10
11 12
TSSYNCIOn
FRAME#
TSYNCn
1
TSYNCn
2
13 14 15 16 1
2
3
4
5
14
15
16
6
7
8
9 10
NOTE 1: TSYNCn IN FRAME MODE (TIOCR.0 = 0).
NOTE 2: TSYNCn IN MULTIFRAME MODE (TIOCR.0 = 1).
NOTE 3: THIS DIAGRAM ASSUMES BOTH THE CAS MF AND THE CRC-4 MF BEGIN WITH THE TAF FRAME.
Figure 11-25. E1 Transmit-Side Boundary Timing (Elastic Store Disabled)
LSB
MSB
LSB
MSB
CHANNEL 1
CHANNEL 2
CHANNEL 1
CHANNEL 2
A
B
C
D
TCLKn
TSERn
TSYNCn
1
TSYNCn
2
TSIGn
TCHCLKn
TCHBLKn
3
Si
1
A
Sa4
Sa5
Sa6 Sa7 Sa8
D
NOTE 1: TSYNCn IN THE OUTPUT MODE (TIOCR.2 = 1).
NOTE 2: TSYNCn IN THE INPUT MODE (TIOCR.2 = 0).
NOTE 3: TCHBLKn IS PROGRAMMED TO BLOCK CHANNEL 2.
NOTE 4: THE SIGNALING DATA AT TSIGn DURING CHANNEL 1 IS NORMALLY OVERWRITTEN IN THE TRANSMIT
FORMATTER WITH THE CAS MF ALIGNMENT NIBBLE (0000).
NOTE 5: SHOWN IS A TNAF FRAME BOUNDARY.
