DS26519 16-Port T1/E1/J1 Transceiver
181 of 310
Register Name: E1RDMWE1, E1RDMWE2, E1RDMWE3, E1RDMWE4
Register Description: E1 Receive Digital Milliwatt Enable Registers 1 to 4
Register Address: 000h, 001h, 002h, 003h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
(MSB) (LSB)
Bit # 7 6 5 4 3 2 1 0
Name CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1 E1RDMWE1
CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9 E1RDMWE2
CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17 E1RDMWE3
CH32 CH31 CH30 CH29 CH28 CH27 CH26 CH25 E1RDMWE4
Bits 7 to 0: E1 Receive Digital Milliwatt Enable for Channels 1 to 32 (CH[1:32])
0 = Do not affect the receive data associated with this channel.
1 = Replace the receive data associated with this channel with digital milliwatt code.
Register Name: TDMWE1, TDMWE2, TDMWE3, TDMWE4 (T1 and E1 Modes)
Register Description: Transmit Digital Milliwatt Enable Registers 1 to 4
Register Address: 100h, 101h, 102h, 103h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
(MSB)
(LSB)
Bit # 7 6 5 4 3 2 1 0
Name CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1 TDMWE1
CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9 TDMWE2
CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17 TDMWE3
CH32 CH31 CH30 CH29 CH28 CH27 CH26 CH25 TDMWE4
Bits 7 to 0: Transmit Digital Milliwatt Enable for Channels 1 to 32 (CH[1:32])
0 = Do not affect the transmit data associated with this channel.
1 = Replace the transmit data associated with this channel with digital milliwatt code.
