DS26519 16-Port T1/E1/J1 Transceiver
32 of 310
NAME PIN TYPE FUNCTION
ARVSS1 A2
ARVSS2 N3
ARVSS3 W2
ARVSS4 AB1
ARVSS5 AB22
ARVSS6 J20
ARVSS7 G20
ARVSS8 D21
ARVSS9 AA14
ARVSS10 Y13
ARVSS11 AB19
ARVSS12 K20
ARVSS13 A10
ARVSS14 C10
ARVSS15 C7
ARVSS16 P2
— Analog Receive V
SS
. These pins are used for analog V
SS
for the receivers.
ACVDD L14, M9 —
1.8V
±5% Analog Clock Conversion V
DD
. These V
DD
inputs are used for the
clock conversion unit (CLAD) of the DS26519.
ACVSS L9, M14 — Analog Clock V
SS
. These pins are used for clock converter analog V
SS
.
DVDD33
J10–J13,
K9, N14,
P10–P13
— 3.3V
±5% Power Supply for I/Os
DVDD18
G12, L8,
M15, T11
— 1.8V
±5% Power Supply for Internal V
DD
DVSS
K10–K13,
L10–L13,
M10–M13,
N10–N13
— Digital Ground
