DS26519 16-Port T1/E1/J1 Transceiver
111 of 310
FRAMER REGISTER LIST
ADDRESS NAME DESCRIPTION R/W
RIDR30 Receive Idle Code Definition Register 30 (E1 Mode)
T1RDMWE3 T1 Receive Digital Milliwatt Enable Register 3 (T1 Mode Only)
03Eh
RIDR31 Receive Idle Code Definition Register 31 (E1 Mode)
R/W
03Fh RIDR32 Receive Idle Code Definition Register 32 (E1 Mode) —
040h RS1 Receive-Signaling Register 1 R
041h RS2 Receive-Signaling Register 2 R
042h RS3 Receive-Signaling Register 3 R
043h RS4 Receive-Signaling Register 4 R
044h RS5 Receive-Signaling Register 5 R
045h RS6 Receive-Signaling Register 6 R
046h RS7 Receive-Signaling Register 7 R
047h RS8 Receive-Signaling Register 8 R
048h RS9 Receive-Signaling Register 9 R
049h RS10 Receive-Signaling Register 10 R
04Ah RS11 Receive-Signaling Register 11 R
04Bh RS12 Receive-Signaling Register 12 R
04Ch RS13 Receive-Signaling Register 13 (E1 Mode only) —
04Dh RS14 Receive-Signaling Register 14 (E1 Mode only) —
04Eh RS15 Receive-Signaling Register 15 (E1 Mode only) —
04Fh RS16 Receive-Signaling Register 16 (E1 Mode only) —
050h LCVCR1 Line Code Violation Count Register 1 R
051h LCVCR2 Line Code Violation Count Register 2 R
052h PCVCR1 Path Code Violation Count Register 1 R
053h PCVCR2 Path Code Violation Count Register 2 R
054h FOSCR1 Frames Out of Sync Count Register 1 R
055h FOSCR2 Frames Out of Sync Count Register 2 R
056h E1EBCR1 E-Bit Count 1 (E1 Mode Only) R
057h E1EBCR2 E-Bit Count 2 (E1 Mode Only) R
058h FEACR1 Error Count A Register 1 R/W
059h FEACR2 Error Count A Register 2 R/W
05Ah FEBCR1 Error Count B Register 1 R/W
05Bh FEBCR2 Error Count B Register 2 R/W
060h RDS0M Receive DS0 Monitor Register R
061h — Reserved —
T1RFDL Receive FDL Register (T1 Mode)
062h
E1RRTS7 Receive Real-Time Status Register 7 (E1 Mode)
R
063h T1RBOC Receive BOC Register (T1 Mode) R
T1RSLC1 Receive SLC-96 Data Link Register 1 (T1 Mode)
064h
E1RAF E1 Receive Align Frame Register (E1 Mode)
R
T1RSLC2 Receive SLC-96 Data Link Register 2 (T1 Mode)
065h
E1RNAF E1 Receive Non-Align Frame Register (E1 Mode)
R
T1RSLC3 Receive SLC-96 Data Link Register 3 (T1 Mode)
066h
E1RsiAF E1 Received Si Bits of the Align Frame Register (E1 Mode)
R
067h E1RSiNAF Received Si Bits of the Non-Align Frame Register (E1 Mode) R
068h E1RRA Received Remote Alarm Register (E1 Mode) R
069h E1RSa4 E1 Receive Sa4 Bits Register (E1 Mode Only) R
06Ah E1RSa5 E1 Receive Sa5 Bits Register (E1 Mode Only) R
06Bh E1RSa6 E1 Receive Sa6 Bits Register (E1 Mode Only) R
06Ch E1RSa7 E1 Receive Sa7 Bits Register (E1 Mode Only) R
06Dh E1RSa8 Receive Sa8 Bits Register (E1 Mode Only) R
06Eh SaBITS E1 Receive SaX Bits Register R
06Fh Sa6CODE Received Sa6 Codeword Register R
070h–07Fh — Reserved —
