DS26519 16-Port T1/E1/J1 Transceiver
223 of 310
Register Name: E1TSiAF (E1 Mode)
Register Description: Transmit Si Bits of the Align Frame Register
Register Address: 166h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name TSiF14 TSiF12 TSiF10 TSiF8 TSiF6 TSiF4 TSiF2 TSiF0
Default 0 0 0 0 0 0 0 0
Bit 7: Si Bit of Frame 14 (TSiF14)
Bit 6: Si Bit of Frame 12 (TSiF12)
Bit 5: Si Bit of Frame 10 (TSiF10)
Bit 4: Si Bit of Frame 8 (TSiF8)
Bit 3: Si Bit of Frame 6 (TSiF6)
Bit 2: Si Bit of Frame 4 (TSiF4)
Bit 1: Si Bit of Frame 2 (TSiF2)
Bit 0: Si Bit of Frame 0 (TSiF0)
Register Name: E1TSiNAF (E1 Mode Only)
Register Description: Transmit Si Bits of the Non-Align Frame Register
Register Address: 167h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name TSiF15 TSiF13 TSiF11 TSiF9 TSiF7 TSiF5 TSiF3 TSiF1
Default 0 0 0 0 0 0 0 0
Bit 7: Si Bit of Frame 15 (TSiF15)
Bit 6: Si Bit of Frame 13 (TSiF13)
Bit 5: Si Bit of Frame 11 (TSiF11)
Bit 4: Si Bit of Frame 9 (TSiF9)
Bit 3: Si Bit of Frame 7 (TSiF7)
Bit 2: Si Bit of Frame 5 (TSiF5)
Bit 1: Si Bit of Frame 3 (TSiF3)
Bit 0: Si Bit of Frame 1 (TSiF1)
