DS26519 16-Port T1/E1/J1 Transceiver
203 of 310
Register Name:
RIM7 (T1 Mode)
Register Description:
Receive Interrupt Mask Register 7 (BOC:FDL)
Register Address:
0A6h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name — —
RRAI-CI
RAIS-CI
RSLC96
RFDLF
BC BD
Default
0 0 0 0 0 0 0 0
Note: See
for E1 Mode
.
Bit 5: Receive RAI-CI (RRAI-CI)
0 = Interrupt masked.
1 = Interrupt enabled.
Bit 4: Receive AIS-CI (RAIS-CI)
0 = Interrupt masked.
1 = Interrupt enabled.
Bit 3: Receive SLC-96 (RSLC96)
0 = Interrupt masked.
1 = Interrupt enabled.
Bit 2: Receive FDL Register Full (RFDLF)
0 = Interrupt masked.
1 = Interrupt enabled.
Bit 1: BOC Clear Event (BC)
0 = Interrupt masked.
1 = Interrupt enabled.
Bit 0: BOC Detect Event (BD)
0 = Interrupt masked.
1 = Interrupt enabled.
Register Name:
RIM7 (E1 Mode)
Register Description:
Receive Interrupt Mask Register 7 (BOC:FDL)
Register Address:
0A6h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name
— — — — — —
Sa6CD
SaXCD
Default
0 0 0 0 0 0 0 0
Note: See
for T1 Mode.
Bit 1: Sa6 Codeword Detect (Sa6CD). This bit will enable the interrupt generated when a valid codeword (per
ETS 300 233) is detected in the Sa6 bits.
0 = Interrupt masked.
1 = Interrupt enabled.
Bit 0: SaX Change Detect (SaXCD). This bit will enable the interrupt generated when a change of state is
detected in any of the unmasked SaX bit positions. The masked or unmasked SaX bits are selected by the
register.
0 = Interrupt masked.
1 = Interrupt enabled.
