DS26519 16-Port T1/E1/J1 Transceiver

56 of 310

Figure 9-15. RSYNCn Input in H.100 (CT Bus) Mode





















BIT 8

BIT 1

BIT 2

RSYNCn

1

RSYNCn

2

RSYSCLKn

RSERn

t

BC

3

NOTE 1: RSYNCn INPUT MODE IN NORMAL OPERATION.
NOTE 2: RSYNCn INPUT MODE, H100EN = 1 AND RSYNCINV = 1.
NOTE 3: t

BC

(BIT CELL TIME) = 122ns (typ). t

BC

= 244ns or 488ns ALSO ACCEPTABLE.

Figure 9-16. TSSYNCIOn (Input Mode) Input in H.100 (CT Bus) Mode

BIT 8

BIT 1

BIT 2

TSSYNCIOn

1

TSSYNCIOn

2

TSYSCLKn

TSERn

t

BC

3

NOTE 1: TSSYNCIOn IN NORMAL OPERATION.
NOTE 2: TSSYNCIOn WITH H100EN = 1 and TSSYNCINV = 1.
NOTE 3: t

BC

(BIT CELL TIME) = 122ns (typ). t

BC

= 244ns OR 488ns ALSO ACCEPTABLE.
