DS26519 16-Port T1/E1/J1 Transceiver
238 of 310
Register Name:
TBPBS
Register Description:
Transmit BERT Port Bit Suppress Register
Register Address:
18Bh + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
#
7 6 5 4 3 2 1 0
Name BPBSE8 BPBSE7 BPBSE6 BPBSE5 BPBSE4 BPBSE3 BPBSE2 BPBSE1
Default
0 0 0 0 0 0 0 0
Bit 7: Transmit Channel Bit 8 Suppress (BPBSE8). MSB of the channel. Set to one to stop this bit from being
used.
Bit 6: Transmit Channel Bit 7 Suppress (BPBSE7). Set to one to stop this bit from being used.
Bit 5: Transmit Channel Bit 6 Suppress (BPBSE6). Set to one to stop this bit from being used.
Bit 4: Transmit Channel Bit 5 Suppress (BPBSE5). Set to one to stop this bit from being used.
Bit 3: Transmit Channel Bit 4 Suppress (BPBSE4). Set to one to stop this bit from being used.
Bit 2: Transmit Channel Bit 3 Suppress (BPBSE3). Set to one to stop this bit from being used.
Bit 1: Transmit Channel Bit 2 Suppress (BPBSE2). Set to one to stop this bit from being used.
Bit 0: Transmit Channel Bit 1 Suppress (BPBSE1). LSB of the channel. Set to one to stop this bit from being
used.
Register Name:
TSYNCC
Register Description:
Transmit Synchronizer Control Register
Register Address:
18Eh + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name
— — — — —
TSEN
SYNCE
RESYNC
—
—
—
—
CRC4 TSEN SYNCE
RESYNC
Default
0 0 0 0 0 0 0 0
Bit 3: CRC-4 Enable (CRC4) (E1 Mode Only)
0 = Do not search for the CRC-4 multiframe word.
1 = Search for the CRC-4 multiframe word.
Bit 2: Transmit Synchronizer Enable (TSEN)
0 = Transmit synchronizer disabled.
1 = Transmit synchronizer enabled.
Bit 1: Sync Enable (SYNCE)
0 = Auto resync enabled.
1 = Auto resync disabled.
Bit 0: Resynchronize (RESYNC). When toggled from low to high, a resynchronization of the transmit-side framer
is initiated. Must be cleared and set again for a subsequent resync.
