DS26519 16-Port T1/E1/J1 Transceiver
127 of 310
ADDR NAME BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0
1CAh THSCS3 CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17
— — — — — — — —
1CBh THSCS4
CH32 CH31 CH30 CH29 CH28 CH27 CH26 CH25
1CCh TGCCS1 CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
1CDh TGCCS2 CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9
1CEh TGCCS3 CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17
— — — — — — — —
1CFh TGCCS4
CH32 CH31 CH30 CH29 CH28 CH27 CH26 CH25(F-bit)
1D0h PCL1 CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
1D1h PCL2 CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9
1D2h PCL3 CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17
— — — — — — — —
1D3h PCL4
CH32 CH31 CH30 CH29 CH28 CH27 CH26 CH25
1D4h TBPCS1 CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
1D5h TBPCS2 CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9
1D6h TBPCS3 CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17
— — — — — — — —
1D7h TBPCS4
CH32 CH31 CH30 CH29 CH28 CH27 CH26 CH25
*RLS6 is reserved for future use.
**Currently, RLS2 does not create an interrupt, therefore this bit is not used in T1 mode.
