background image

DS26519 16-Port T1/E1/J1 Transceiver

212 of 310

Register Name:

RGCCS1, RGCCS2, RGCCS3, RGCCS4

Register Description:

Receive Gapped Clock Channel Select Registers 1 to 4

Register Address:

0CCh, 0CDh, 0CEh, 0CFh + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16


(MSB)

(LSB)

Bit

# 7 6 5 4 3 2 1 0

Name CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1

RGCCS1

CH16

CH15

CH14

CH13

CH12 CH11 CH10 CH9 RGCCS2

CH24

CH23

CH22

CH21

CH20 CH19 CH18 CH17 RGCCS3

CH32 CH31 CH30 CH29 CH28 CH27 CH26

CH25

(F-bit)

RGCCS4 (E1
Mode Only)*


Bits 7 to 0: Gapped Clock Channel Select Bits for Receive Channels 1 to 32(CH[1:32]).

0 = No clock is present on RCHCLKn during this channel time.
1 = Force a clock on RCHCLKn during this channel time. The clock will be synchronous with RCLKn if the
elastic store is disabled, and synchronous with RSYSCLKn if the elastic store is enabled.


* Note that RGCCS4 has two functions:

When 2.048MHz backplane mode is selected, this register allows the user to enable the gapped clock on
RCHCLKn for any of the 32 possible backplane channels.

When 1.544MHz backplane mode is selected, the LSB of this register determines whether or not a clock is
generated on RCHCLKn during the F-bit time:


RGCCS4.0 = 0, do not generate a clock during the F-bit.
RGCCS4.0 = 1, generate a clock during the F-bit.


In this mode RGCCS4.1 to RGCCS4.7 should be set to 0.



Register Name:

RCICE1, RCICE2, RCICE3, RCICE4

Register Description:

Receive Channel Idle Code Enable Registers 1 to 4

Register Address:

0D0h, 0D1h, 0D2h, 0D3h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16


(MSB)

(LSB)

Bit

# 7 6 5 4 3 2 1 0

Name CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1

RCICE1

CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9 RCICE2

CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17

RCICE3

CH32 CH31 CH30 CH29 CH28 CH27 CH26 CH25

RCICE4 (E1
Mode Only)


Bits 7 to 0: Receive Channels 1 to 32 Code Insertion Control Bits (CH[1:32])

0 = Do not insert data from the Idle Code Array into the receive data stream.
1 = Insert data from the Idle Code Array into the receive data stream.
