DS26519 16-Port T1/E1/J1 Transceiver
114 of 310
FRAMER REGISTER LIST
ADDRESS NAME DESCRIPTION R/W
118h SSIE1 Software-Signaling Insertion Enable Register 1 R/W
119h SSIE2 Software-Signaling Insertion Enable Register 2 R/W
11Ah SSIE3 Software-Signaling Insertion Enable Register 3 R/W
11Bh SSIE4 Software-Signaling Insertion Enable Register 4 (E1 Mode Only) R/W
11Ch–11Fh — Reserved —
120h TIDR1 Transmit Idle Code Definition Register 1 R/W
121h TIDR2 Transmit Idle Code Definition Register 2 R/W
122h TIDR3 Transmit Idle Code Definition Register 3 R/W
123h TIDR4 Transmit Idle Code Definition Register 4 R/W
124h TIDR5 Transmit Idle Code Definition Register 5 R/W
125h TIDR6 Transmit Idle Code Definition Register 6 R/W
126h TIDR7 Transmit Idle Code Definition Register 7 R/W
127h TIDR8 Transmit Idle Code Definition Register 8 R/W
128h TIDR9 Transmit Idle Code Definition Register 9 R/W
129h TIDR10 Transmit Idle Code Definition Register 10 R/W
12Ah TIDR11 Transmit Idle Code Definition Register 11 R/W
12Bh TIDR12 Transmit Idle Code Definition Register 12 R/W
12Ch TIDR13 Transmit Idle Code Definition Register 13 R/W
12Dh TIDR14 Transmit Idle Code Definition Register 14 R/W
12Eh TIDR15 Transmit Idle Code Definition Register 15 R/W
12Fh TIDR16 Transmit Idle Code Definition Register 16 R/W
130h TIDR17 Transmit Idle Code Definition Register 17 R/W
131h TIDR18 Transmit Idle Code Definition Register 18 R/W
132h TIDR19 Transmit Idle Code Definition Register 19 R/W
133h TIDR20 Transmit Idle Code Definition Register 20 R/W
134h TIDR21 Transmit Idle Code Definition Register 21 R/W
135h TIDR22 Transmit Idle Code Definition Register 22 R/W
136h TIDR23 Transmit Idle Code Definition Register 23 R/W
137h TIDR24 Transmit Idle Code Definition Register 24 R/W
138h TIDR25 Transmit Idle Code Definition Register 25 (E1 Mode Only) R/W
139h TIDR26 Transmit Idle Code Definition Register 26 (E1 Mode Only) R/W
13Ah TIDR27 Transmit Idle Code Definition Register 27 (E1 Mode Only) R/W
13Bh TIDR28 Transmit Idle Code Definition Register 28 (E1 Mode Only) R/W
13Ch TIDR29 Transmit Idle Code Definition Register 29 (E1 Mode Only) R/W
13Dh TIDR30 Transmit Idle Code Definition Register 30 (E1 Mode Only) R/W
13Eh TIDR31 Transmit Idle Code Definition Register 31 (E1 Mode Only) R/W
13Fh TIDR32 Transmit Idle Code Definition Register 32 (E1 Mode Only) R/W
140h TS1 Transmit-Signaling Register 1 R/W
141h TS2 Transmit-Signaling Register 2 R/W
142h TS3 Transmit-Signaling Register 3 R/W
143h TS4 Transmit-Signaling Register 4 R/W
144h TS5 Transmit-Signaling Register 5 R/W
145h TS6 Transmit-Signaling Register 6 R/W
146h TS7 Transmit-Signaling Register 7 R/W
147h TS8 Transmit-Signaling Register 8 R/W
148h TS9 Transmit-Signaling Register 9 R/W
149h TS10 Transmit-Signaling Register 10 R/W
14Ah TS11 Transmit-Signaling Register 11 R/W
14Bh TS12 Transmit-Signaling Register 12 R/W
14Ch TS13 Transmit-Signaling Register 13 R/W
14Dh TS14 Transmit-Signaling Register 14 R/W
14Eh TS15 Transmit-Signaling Register 15 R/W
14Fh TS16 Transmit-Signaling Register 16 R/W
