DS26519 16-Port T1/E1/J1 Transceiver
132 of 310
Register Name GTCR2
Register Description: Global Transceiver Control Register 2
Register Address: 20F0h
Channels: 9 to 16
Bit
# 7 6 5 4 3 2 1 0
Name GPSEL3 GPSEL2 GPSEL1 GPSEL0 — GIBO GCLE GIPI
Default 0 0 0 0 0 0 0 0
Bits 7 to 5: General-Purpose I/O Pins Select (GPSEL[3:1]). GPSEL0 must be set to 1 to output this selection.
Table 10-13. DS26519 GPIO Control (9 to 16)
GPSEL[3:1] GPIO[16:9] OUTPUT
000 RLOFn
001 LOTCn
010 RSIGFn
011 FLOSn
100 ALOSn
101
Logic 0—All 8 GPIOs
110 Logic 1—All 8 GPIOs
111 Reserved
Bit 3: GPIO Select 0 (GPSEL0)
0 = GPIO16:9] are inputs.
1 = GPIO[16:9] are outputs selected by GPSEL[3:1].
Bit 2: Ganged IBO Enable (GIBO). This bit is used to select either the internal mux for IBO operation or an
external “wire-OR” operation. Normally this bit should be set = 0 and the internal mux used.
0 = Use internal IBO mux.
1 = Externally “wire-OR” TSERn and RSERn for IBO operation.
Note: Setting GIBO disables the internal IBO mux. GFCR2 must be set to inform the framers of the IBO
configuration.
Bit 1: Global Counter Latch Enable (GCLE). A low-to-high transition on this bit will, when enabled, latch the
framer performance monitor counters. Each framer can be independently enabled to accept this input. This bit must
be cleared and set again to perform another counter latch.
Bit 0: Global Interrupt Pin Inhibit (GIPI)
0 = Normal Operation. Interrupt pin (
INTB) will toggle low on an unmasked interrupt condition.
1 = Interrupt Inhibit. Interrupt pin (
INTB) is forced high (inactive) when this bit is set.
