DS26519 16-Port T1/E1/J1 Transceiver
166 of 310
Register Name:
FEACR1
Register Description:
Error Count A Register 1
Register Address:
058h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name
FEACR15 FEACR14 FEACR13 FEACR12 FEACR11 FEACR10 FEACR9 FEACR8
Default
0 0 0 0 0 0 0 0
Bits 7 to 0: Error Count A Register 1 Bits 15 to 8 (FEACR[15:8]). FEACR15 is the MSB of the 16-bit Far End A
Counter.
Register Name:
FEACR2
Register Description:
Error Count A Register 2
Register Address:
059h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name FEACR7 FEACR6 FEACR5 FEACR4 FEACR3 FEACR2 FEACR1 FEACR0
Default
0 0 0 0 0 0 0 0
Bits 7 to 0: Error Count A Register 2 Bits 7 to 0 (FEACR[7:0]). FEACR0 is the LSB of the 16-bit Far End A
Counter.
Register Name:
FEBCR1
Register Description:
Error Count B Register 1
Register Address:
05Ah + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name
FEBCR15 FEBCR14 FEBCR13 FEBCR12 FEBCR11 FEBCR10 FEBCR9 FEBCR8
Default
0 0 0 0 0 0 0 0
Bits 7 to 0: Error Count B Register 1 Bits 15 to 8 (FEBCR[15:8]). FEBCR15 is the MSB of the 16-bit Far End
Error B Counter.
Register Name:
FEBCR2
Register Description:
Error Count B Register 2
Register Address:
05Bh + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name FEBCR7 FEBCR6 FEBCR5 FEBCR4 FEBCR3 FEBCR2 FEBCR1 FEBCR0
Default
0 0 0 0 0 0 0 0
Bits 7 to 0: Error Count B Register 2 Bits 7 to 0 (FEBCR[7:0]). FEBCR0 is the LSB of the 16-bit Far End Error B
Counter.
