DS26519 16-Port T1/E1/J1 Transceiver
50 of 310
Table 9-6. RSERn Output Pin Definitions ( GTCR1 .GIBO = 0)
PIN NORMAL USE 4.096MHz IBO 8.192MHz IBO 16.384MHz IBO
RSER1
Receive Serial Data
for Port 1
Combined Receive
Serial Data for
Ports 1 and 2
Combined Receive
Serial Data for
Ports 1–4
Receive Serial Data
for Ports 1–8
RSER2
Receive Serial Data
for Port 2
Reserved Unused Unused
RSER3
Receive Serial Data
for Port 3
Combined Receive
Serial Data for Ports 3
and 4
Unused Unused
RSER4
Receive Serial Data
for Port 4
Unused Unused Unused
RSER5
Receive Serial Data
for Port 5
Combined Receive
Serial Data for Ports 5
and 6
Combined Receive
Serial Data for Ports
5–8
Unused
RSER6
Receive Serial Data
for Port 6
Unused Unused Unused
RSER7
Receive Serial Data
for Port 7
Combined Receive
Serial Data for Ports 7
and 8
Unused Unused
RSER8
Receive Serial Data
for Port 8
Unused Unused Unused
RSER9
Receive Serial Data
for Port 9
Combined Receive
Serial Data for Ports 9
and 10
Combined Receive
Serial Data for Ports
9–12
Receive Serial Data
for Ports 9–16
RSER10
Receive Serial Data
for Port 10
Unused Unused Unused
RSER11
Receive Serial Data
for Port 11
Combined Receive
Serial Data for Ports
11 and 12
Unused Unused
RSER12
Receive Serial Data
for Port 12
Unused Unused Unused
RSER13
Receive Serial Data
for Port 13
Combined Receive
Serial Data for Ports
13 and 14
Combined Receive
Serial Data for Ports
13–16
Unused
RSER14
Receive Serial Data
for Port 14
Unused Unused Unused
RSER15
Receive Serial Data
for Port 15
Combined Receive
Serial Data for Ports
15 and 16
Unused Unused
RSER16
Receive Serial Data
for Port 16
Unused Unused Unused
