Table 9-24 shows some of the registers related to maintenance and alarms.
Table 9-24. Registers Related to Maintenance and Alarms
REGISTER
FRAMER 1
ADDRESSES
FUNCTION
Receive Real-Time Status Register 1 ( RRTS1 ) 0B0h Real-time receive status 1.
Receive Interrupt Mask Register 1( RIM1 ) 0A0h Real-time interrupt mask 1.
Receive Latched Status Register 2 ( RLS2 ) 091h Real-time latched status 2.
Receive Real-Time Status Register 3 ( RRTS3 ) 0B2h Real-time receive status 2.
Receive Latched Status Register 3 ( RLS3 ) 092h Real-time latched status 3.
Receive Interrupt Mask Register 3 ( RIM3 ) 0A2h Real-time interrupt mask 3.
Receive Interrupt Mask Register 4 ( RIM4 ) 0A3h Real-time interrupt mask 3.
Receive Latched Status Register 7 ( RLS7 ) 096h Real-time latched status 7.
Receive Interrupt Mask Register 7 ( RIM7 ) 0A6h Real-time interrupt mask 7.
Transmit Latched Status Register 1 ( TLS1 ) 190h Loss of transmit clock status, etc.
Transmit Latched Status Register 3
(Synchronizer) (
TLS3 )
192h Loss of frame status.
Receive DS0 Monitor Register ( RDS0M ) 060h Receive DS0 monitor.
Error-Counter Configuration Register ( ERCNT ) 086h Configuration of the error counters.
Line Code Violation Count Register 1
(
LCVCR1 )
050h Line code violation counter 1.
Line Code Violation Count Register 2
(
LCVCR2 )
051h Line code violation counter 2.
Path Code Violation Count Register 1
(
PCVCR1 )
052h Receive path code violation counter 1.
Path Code Violation Count Register 2
(
PCVCR2 )
053h Receive path code violation counter 2.
Frames Out of Sync Count Register 1
(
FOSCR1 )
054h Receive frame out of sync counter 1
Frames Out of Sync Count Register 2
(
FOSCR2 )
055h Receive frame out of sync counter 2
E-Bit Count Register 1 ( E1EBCR1 ) 056h E-bit count register 1.
E-Bit Count Register 2 ( E1EBCR2 ) 057h E-bit count register 2.
Note: The addresses shown above are for Framer 1.
