DS26519 16-Port T1/E1/J1 Transceiver
265 of 310
Register Name:
BEC1
Register Description:
BERT Error Count Register 1
Register Address:
110Bh + (10h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name EC7 EC6 EC5 EC4 EC3 EC2 EC1 EC0
Default
0 0 0 0 0 0 0 0
Bits 7 to 0: Error Counter Bits 7 to 0 (EC[7:0]). EC0 is the LSB of the 24-bit counter.
Register Name:
BEC2
Register Description:
BERT Error Count Register 2
Register Address:
110Ch + (10h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name EC15 EC14 EC13 EC12 EC11 EC10 EC9 EC8
Default
0 0 0 0 0 0 0 0
Bits 7 to 0: Error Counter Bits 15 to 8 (EC[15:8])
Register Name:
BEC3
Register Description:
BERT Error Count Register 3
Register Address:
110Dh + (10h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name EC23 EC22 EC21 EC20 EC19 EC18 EC17 EC16
Default
0 0 0 0 0 0 0 0
Bits 7 to 0: Error Counter Bits 23 to 16 (EC[23:16]). EC23 is the MSB of the 24-bit counter.
