DS26519 16-Port T1/E1/J1 Transceiver
122 of 310
ADDR NAME BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0
RLS3 (E1) LORCC — V52LNKC RDMAC LORCD — V52LNKD RDMAD
093h RLS4 RESF RESEM RSLIP — RSCOS 1SEC TIMER RMF
094h RLS5 — — ROVR RHOBT RPE RPS RHWMS RNES
RLS7 (T1) — — RRAI-CI RAIS-CI RSLC96 RFDLF BC BD
096h
RLS7 (E1) — — — — — — Sa6CD SaXCD
097h — — — — — — — — —
098h RSS1 CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
099h RSS2 CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9
09Ah RSS3 CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17
— — — — — — — —
09Bh RSS4
CH32 CH31 CH30 CH29 CH28 CH27 CH26 CH25
C7 C6 C5 C4 C3 C2 C1 C0
09Ch T1RSCD1
— — — — — — — —
C7 C6 C5 C4 C3 C2 C1 C0
09Dh T1RSCD2
— — — — — — — —
09Fh RIIR — RLS7 RLS6* RLS5 RLS4 RLS3 RLS2** RLS1
0A0h RIM1 RRAIC RAISC RLOSC RLOFC RRAID RAISD RLOSD RLOFD
— — — — — — — —
0A1h RIM2
— — — — RSA1 RSA0 RCMF RAF
RIM3 (T1) LORCC LSPC LDNC LUPC LORCD LSPD LDND LUPD
0A2h
RIM3 (E1) LORCC — V52LNKC RDMAC LORCD — V52LNKD RDMAD
0A3h RIM4 RESF RESEM RSLIP — RSCOS 1SEC TIMER RMF
0A4h RIM5 — — ROVR RHOBT RPE RPS RHWMS RNES
RIM7 (T1) — — RRAI-CI RAIS-CI RSLC96 RFDLF BC BD
0A6h
RIM7 (E1) — — — — Sa6CD SaXCD
0A8h RSCSE1 CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
0A9h RSCSE2 CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9
0AAh RSCSE3 CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17
— — — — — — — —
0ABh RSCSE4
CH32 CH31 CH30 CH29 CH28 CH27 CH26 CH25
C7 C6 C5 C4 C3 C2 C1 C0
0ACh T1RUPCD1
— — — — — — — —
C7 C6 C5 C4 C3 C2 C1 C0
0ADh T1RUPCD2
— — — — — — — —
C7 C6 C5 C4 C3 C2 C1 C0
0AEh T1RDNCD1
— — — — — — — —
C7 C6 C5 C4 C3 C2 C1 C0
0AFh T1RDNCD2
— — — — — — — —
0B0h RRTS1 — — — — RRAI RAIS RLOS RLOF
RRTS3 (T1) — — — — LORC LSP LDN LUP
0B2h
RRTS3 (E1) — — — — LORC — V52LNK RDMA
0B4h RRTS5 — PS2 PS1 PS0 — — RHWM RNE
0B5h RHPBA MS RPBA6 RPBA5 RPBA4 RPBA3 RPBA2 RPBA1 RPBA0
0B6h RHF RHD7 RHD6 RHD5 RHD4 RHD3 RHD2 RHD1 RHD0
0C0h RBCS1 CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
0C1h RBCS2 CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9
0C2h RBCS3 CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17
— — — — — — — —
0C3h RBCS4
CH32 CH31 CH30 CH29 CH28 CH27 CH26 CH25
0C4h RCBR1 CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
