DS26519 16-Port T1/E1/J1 Transceiver
118 of 310
10.2 Register Bit Maps
10.2.1 Global Register Bit Map
Table 10-7. Global Register Bit Map
ADDR
(1–8)
NAME BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0
00F0h GTCR1 GPSEL3 GPSEL2 GPSEL1 GPSEL0 — GIBO GCLE GIPI
00F1h GFCR1 IBOMS1 IBOMS0 BPCLK1 BPCLK0 — RFMSS TCBCS RCBCS
00F2h GTCR3 — — — — — — TSSYNCIOSEL TSYNCSEL
00F3h GTCCR1 BPREFSEL3 BPREFSEL2 BPREFSEL1 BPREFSEL0 BFREQSEL FREQSEL MPS1 MPS0
00F4h GTCCR3 — RSYSCLKSEL TSYSCLKSEL TCLKSEL CLKOSEL3 CLKOSEL2 CLKOSEL1 CLKOSEL0
00F5h — — — — — — — — —
00F6h GSRR1 — — — — — LRST BRST FRST
00F7h — — — — — — — — —
00F8h IDR ID7 ID6 ID5 ID4 ID3 ID2 ID1 ID0
00F9h GFISR1 FIS8 FIS7 FIS6 FIS5 FIS4 FIS3 FIS2 FIS1
00FAh GBISR1 BIS8 BIS7 BIS6 BIS5 BIS4 BIS3 BIS2 BIS1
00FBh GLISR1 LIS8 LIS7 LIS6 LIS5 LIS4 LIS3 LIS2 LIS1
00FCh GFIMR1 FIM8 FIM7 FIM6 FIM5 FIM4 FIM3 FIM2 FIM1
00FDh GBIMR1 BIM8 BIM7 BIM6 BIM5 BIM4 BIM3 BIM2 BIM1
00FEh GLIMR1 LIM8 LIM7 LIM6 LIM5 LIM4 LIM3 LIM2 LIM1
00FFh GPIORR1 GPIO8 GPIO7 GPIO6 GPIO5 GPIO4 GPIO3 GPIO2 GPIO1
ADDR
(9–16)
NAME BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0
20F0h GTCR2 GPSEL3 GPSEL2 GPSEL1 GPSEL0 — GIBO GCLE GIPI
20F1h GFCR2 IBOMS1 IBOMS0 BPCLK1 BPCLK0 — RFMSS TCBCS RCBCS
20F2h GTCR4 — — — — — — TSSYNCIOSEL TSYNCSEL
20F3h GTCCR2 BPREFSEL3 BPREFSEL2 BPREFSEL1 BPREFSEL0 BFREQSEL — — —
20F4h GTCCR4 — RSYSCLKSEL TSYSCLKSEL TCLKSEL — — — —
20F5h — — — — — — — — —
20F6h GSRR2 — — — — — LRST BRST FRST
20F7h — — — — — — — — —
20F9h GFISR2 FIS16 FIS15 FIS14 FIS13 FIS12 FIS11 FIS10 FIS9
20FAh GBISR2 BIS16 BIS15 BIS14 BIS13 BIS13 BIS11 BIS10 BIS9
20FBh GLISR2 LIS16 LIS15 LIS14 LIS13 LIS12 LIS11 LIS10 LIS9
20FCh GFIMR2 FIM16 FIM15 FIM14 FIM13 FIM12 FIM11 FIM10 FIM9
20FDh GBIMR2 BIM16 BIM15 BIM14 BIM13 BIM12 BIM11 BIM10 BIM9
20FEh GLIMR2 LIM16 LIM15 LIM14 LIM13 LIM12 LIM11 LIM10 LIM9
20FFh GPIORR2 GPIO16 GPIO15 GPIO14 GPIO13 GPIO12 GPIO11 GPIO10 GPIO9
