DS26519 16-Port T1/E1/J1 Transceiver
248 of 310
Register Name: TGCCS1, TGCCS2, TGCCS3, TGCCS4
Register Description: Transmit Gapped Clock Channel Select Registers 1 to 4
Register Address: 1CCh, 1CDh, 1CEh, 1CFh + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
(MSB)
(LSB)
Bit # 7 6 5 4 3 2 1 0
Name CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1 TGCCS1
CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9 TGCCS2
CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17 TGCCS3
CH32 CH31 CH30 CH29 CH28 CH27 CH26
CH25
(F-bit)
TGCCS4 (E1
Mode Only)*
Bits 7 to 0: Transmit Channels 1 to 32 Gapped Clock Channel Select Bits (CH[1:32])
0 = no clock is present on TCHCLK during this channel time
1 = force a clock on TCHCLK during this channel time. The clock will be synchronous with TCLKn if the
elastic store is disabled, and synchronous with TSYSCLKn if the elastic store is enabled.
* Note that TGCCS4 has two functions:
When 2.048MHz backplane mode is selected, this register allows the user to enable the gapped clock on
TCHCLK for any of the 32 possible backplane channels.
When 1.544MHz backplane mode is selected, the LSB of this register determines whether or not a clock is
generated on TCHCLK during the F-bit time:
TGCCS4.0 = 0, do not generate a clock during the F-bit.
TGCCS4.0 = 1, generate a clock during the F-bit.
In this mode TGCCS4.1 to TGCCS4.7 should be set to 0.
Register Name: PCL1, PCL2, PCL3, PCL4
Register Description: Per-Channel Loopback Enable Registers 1 to 4
Register Address: 1D0h, 1D1h, 1D2h, 1D3h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
(MSB)
(LSB)
Bit # 7 6 5 4 3 2 1 0
Name CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1 PCL1
CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9 PCL2
CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17 PCL3
CH32 CH31 CH30 CH29 CH28 CH27 CH26 CH25
PCL4 (E1
Mode Only)
Bits 7 to 0: Per-Channel Loopback Enable for Channels 1 to 32 (CH[1:32])
0 = Loopback disabled.
1 = Enable loopback. Source data from the corresponding receive channel.
