DS26519 16-Port T1/E1/J1 Transceiver
110 of 310
10.1.2 Framer Register List
Table 10-4. Framer Register List
Note that only Framer 1 address is presented here. The same set of registers definitions applies for transceivers 2 to 16 in accordance with the
DS26519 map offsets. Transceiver offset is (2000 x [(n - 1) / 8] + (n - 1) x 200 hex], where n designates the transceiver in question.
FRAMER REGISTER LIST
ADDRESS NAME DESCRIPTION R/W
000h E1RDMWE1 E1 Receive Digital Milliwatt Enable Register 1 R/W
001h E1RDMWE2 E1 Receive Digital Milliwatt Enable Register 2 R/W
002h E1RDMWE3 E1 Receive Digital Milliwatt Enable Register 3 R/W
003h E1RDMWE4 E1 Receive Digital Milliwatt Enable Register 4 R/W
004h–00Fh — Reserved —
010h RHC Receive HDLC Control Register R/W
011h RHBSE Receive HDLC Bit Suppress Register R/W
012h RDS0SEL Receive Channel Monitor Select Register R/W
013h RSIGC Receive-Signaling Control Register R/W
T1RCR2 Receive Control Register 2 (T1 Mode)
014h
E1RSAIMR Receive Sa-Bit Interrupt Mask Register (E1 Mode)
R/W
015h T1RBOCC Receive BOC Control Register (T1 Mode Only) R/W
016h–01Fh — Reserved —
020h RIDR1 Receive Idle Code Definition Register 1 R/W
021h RIDR2 Receive Idle Code Definition Register 2 R/W
022h RIDR3 Receive Idle Code Definition Register 3 R/W
023h RIDR4 Receive Idle Code Definition Register 4 R/W
024h RIDR5 Receive Idle Code Definition Register 5 R/W
025h RIDR6 Receive Idle Code Definition Register 6 R/W
026h RIDR7 Receive Idle Code Definition Register 7 R/W
027h RIDR8 Receive Idle Code Definition Register 8 R/W
028h RIDR9 Receive Idle Code Definition Register 9 R/W
029h RIDR10 Receive Idle Code Definition Register 10 R/W
02Ah RIDR11 Receive Idle Code Definition Register 11 R/W
02Bh RIDR12 Receive Idle Code Definition Register 12 R/W
02Ch RIDR13 Receive Idle Code Definition Register 13 R/W
02Dh RIDR14 Receive Idle Code Definition Register 14 R/W
02Eh RIDR15 Receive Idle Code Definition Register 15 R/W
02Fh RIDR16 Receive Idle Code Definition Register 16 R/W
030h RIDR17 Receive Idle Code Definition Register 17 R/W
031h RIDR18 Receive Idle Code Definition Register 18 R/W
032h RIDR19 Receive Idle Code Definition Register 19 R/W
033h RIDR20 Receive Idle Code Definition Register 20 R/W
034h RIDR21 Receive Idle Code Definition Register 21 R/W
035h RIDR22 Receive Idle Code Definition Register 22 R/W
036h RIDR23 Receive Idle Code Definition Register 23 R/W
037h RIDR24 Receive Idle Code Definition Register 24 R/W
T1RSAOI1 Receive-Signaling All-Ones Insertion Register 1 (T1 Mode Only)
038h
RIDR25 Receive Idle Code Definition Register 25 (E1 Mode)
R/W
T1RSAOI2 Receive-Signaling All-Ones Insertion Register 2 (T1 Mode Only)
039h
RIDR26 Receive Idle Code Definition Register 26 (E1 Mode)
R/W
T1RSAOI3 Receive-Signaling All-Ones Insertion Register 3 (T1 Mode Only)
03Ah
RIDR27 Receive Idle Code Definition Register 27 (E1 Mode)
R/W
03B RIDR28 Receive Idle Code Definition Register 28 (E1 Mode) —
T1RDMWE1 T1 Receive Digital Milliwatt Enable Register 1 (T1 Mode Only)
03C
RIDR29 Receive Idle Code Definition Register 29 (E1 Mode)
R/W
03Dh T1RDMWE2 T1 Receive Digital Milliwatt Enable Register 2 (T1 Mode Only) R/W
