DS26519 16-Port T1/E1/J1 Transceiver

27 of 310

NAME PIN

TYPE

FUNCTION

RSIG1 D4

RSIG2 B16

RSIG3 J7

RSIG4 R10

RSIG5 U10

RSIG6 V11

RSIG7 H17

RSIG8 V19

RSIG9 F6

RSIG10 P20

RSIG11 D2

RSIG12 Y4

RSIG13 J3

RSIG14 K3

RSIG15 J14

RSIG16 P15

Ouptut

Receive Signaling.

Outputs signaling bits in a PCM format. Updated on rising

edges of RCLKn when the receive-side elastic store is disabled. Updated on the
rising edges of RSYSCLKn when the receive-side elastic store is enabled. See

Table 9-7

.

GPIO1 P22

GPIO2 J17

GPIO3 N21

GPIO4 B13

GPIO5 F10

GPIO6 W19

GPIO7 P19

GPIO8 N18

GPIO9 T22

GPIO10 K17

GPIO11 M19

GPIO12 K16

GPIO13 R21

GPIO14 J15

GPIO15 R22

GPIO16 J16

Output

General-Purpose I/O 1 to 16.

These pins can be used as an input or a

programmable output, or be used to output the following signals: analog loss,
receive signaling freeze, framer LOS, receive loss of frame, or loss of transmit
clock. These pins are controlled by

GTCR1

.GPSEL[3:0] and

GTCR2

. GPSEL[3:0].

These pins are controlled on a per-8 basis (GPIO[8:1] and GPIO[16:9]).
