DS26519 16-Port T1/E1/J1 Transceiver
52 of 310
Table 9-8. TSERn Input Pin Definitions ( GTCR1 .GIBO = 0)
PIN NORMAL USE 4.096MHz IBO 8.192MHz IBO 16.384MHz IBO
TSER1
Transmit Serial Data
for Port 1
Combined Transmit
Serial Data for
Ports 1 and 2
Combined Transmit
Serial Data for Ports
1–4
Transmit Serial Data
for Ports 1–8
TSER2
Transmit Serial Data
for Port 2
Unused Unused Unused
TSER3
Transmit Serial Data
for Port 3
Combined Transmit
Serial Data for
Ports 3 and 4
Unused Unused
TSER4
Transmit Serial Data
for Port 4
Unused Unused Unused
TSER5
Transmit Serial Data
for Port 5
Combined Transmit
Serial Data for
Ports 5 and 6
Combined Transmit
Serial Data for
Ports 5–8
Unused
TSER6
Transmit Serial Data
for Port 6
Unused Unused Unused
TSER7
Transmit Serial Data
for Port 7
Combined Transmit
Serial Data for
Ports 7 and 8
Unused Unused
TSER8
Transmit Serial Data
for Port 8
Unused Unused Unused
TSER9
Transmit Serial Data
for Port 9
Combined Transmit
Serial Data for Ports 9
and 10
Combined Transmit
Serial Data for Ports
9–12
Transmit Serial Data
for Ports 9–16
TSER10
Transmit Serial Data
for Port 10
Unused Unused Unused
TSER11
Transmit Serial Data
for Port 11
Combined Transmit
Serial Data for Ports
11 and 12
Unused Unused
TSER12
Transmit Serial Data
for Port 12
Unused Unused Unused
TSER13
Transmit Serial Data
for Port 13
Combined Transmit
Serial Data for Ports
13 and 14
Combined Transmit
Serial Data for Ports
13–16
Unused
TSER14
Transmit Serial Data
for Port 14
Unused Unused Unused
TSER15
Transmit Serial Data
for Port 15
Combined Transmit
Serial Data for Ports
15 and 16
Unused Unused
TSER16
Transmit Serial Data
for Port 16
Unused Unused Unused
