Register Name:
T1RSLC1, T1RSLC2, T1RSLC3 (T1 Mode)
Register Description:
Receive SLC96 Data Link Registers
Register Address:
064h, 065h, 066h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
(MSB)
(LSB)
Bit
# 7 6 5 4 3 2 1 0
Name C8 C7 C6 C5 C4 C3 C2 C1
T1RSLC1
M2 M1 S=0 S=1 S=0 C11 C10 C9
T1RSLC2
S=1 S4 S3 S2 S1 A2 A1 M3
T1RSLC3
Note: These registers have an alternate definition for E1 mode. See
, and
Register Name:
E1RAF (E1 Mode)
Register Description:
E1 Receive Align Frame Register
Register Address:
064h + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
Bit
# 7 6 5 4 3 2 1 0
Name
Si 0 0 1 1 0 1 1
Default
0 0 0 0 0 0 0 0
Note: This register has an alternate definition for T1 mode. See
.
Bit 7: International Bit (Si)
Bit 6: Frame Alignment Signal Bit (0)
Bit 5: Frame Alignment Signal Bit (0)
Bit 4: Frame Alignment Signal Bit (1)
Bit 3: Frame Alignment Signal Bit (1)
Bit 2: Frame Alignment Signal Bit (0)
Bit 1: Frame Alignment Signal Bit (1)
Bit 0: Frame Alignment Signal Bit (1)
