DS26519 16-Port T1/E1/J1 Transceiver
71 of 310
9.9.6 E1 Data Link
Table 9-23 shows the registers related to E1 data link.
Table 9-23. Registers Related to E1 Data Link
REGISTER
FRAMER 1
ADDRESSES
FUNCTION
E1 Receive Align Frame Register ( E1RAF ) 064h Receive frame alignment register.
E1 Receive Non-Align Frame Register
Register (
E1RNAF )
065h Receive non-frame alignment register.
E1 Received Si Bits of the Align Frame
Register (
E1RsiAF )
066h Receive Si bits of the frame alignment frames.
Received Si Bits of the Non-Align Frame
Register
E1RSiNAF )
067h
Receive Si bits of the non-frame alignment
frames.
Received Sa4 to Sa8 Bits Register
(
E1RSa4 to E1RSa8 )
069h, 06Ah,
06Bh, 06Ch,
06Dh
Receive Sa bits.
Transmit Align Frame Register ( E1TAF ) 164h Transmit align frame register.
Transmit Non-Align Frame Register
( E1TNAF )
165h Transmit non-align frame register.
Transmit Si Bits of the Align Frame
Register ( E1TSiAF )
166h Transmit Si bits of the frame alignment frames.
Transmit Si Bits of the Non-Align Frame
Register (
E1TSiNAF )
167h
Transmit Si bits of the non-frame alignment
frames.
Transmit Sa4 to Sa8 Bits Register
(
E1TSa4 to E1TSa8 )
169h, 16Ah,
16Bh, 16Ch,
16Dh
Transmit Sa4 to Sa8.
E1 Transmit Sa-Bit Control Register
( E1TSACR )
114h Transmit sources of Sa control.
Note: The addresses shown are for Framer 1.
