DS26519 16-Port T1/E1/J1 Transceiver

259 of 310

Register Name:

LRCR

Register Description:

LIU Receive Control Register

Register Address:

1008h + (20h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16


Bit

# 7 6 5 4 3 2 1 0

Name

RG703

— — —

RTR

RMONEN

RSMS1

RSMS0

Default

0 0 0 0 0 0 0 0


Bit 7: Receive G.703 Clock (RG703).

If this bit is set, the receiver expects a 2.048MHz or 1.544MHz clock from

the RTIPn/RRINGn, based on the selection of T1 (1.544) or E1 (2.048) mode in the

LTRCR

register.


Bit 3: Receiver Turns Ratio (RTR)

0 = Receive transformer turns ratio is 1:1.
1 = Receive transformer turns ratio is 2:1. This option should only be used in short-haul applications.
Note: Internal impedance match is not available for this mode.

Bit 2: Receiver Monitor Mode Enable (RMONEN)

0 = Disable receive monitor mode.
1 = Enable receive monitor mode. Resistive gain is added with the maximum sensitivity. The receiver
sensitivity is determined by RSMS1 and RSMS0.

Bits 1 and 0: Receiver Sensitivity/Monitor Gain Select (RSMS[1:0]).

These bits

are used to select the receiver

sensitivity level and additional gain in monitoring applications. The monitor mode (RMONEN) adds resistive gain to
compensate for the signal loss caused by the isolation resistors. See

Table 10-23

and

Table 10-24.

Table 10-23. Receiver Sensitivity Selection with Monitor Mode Disabled

RMONEN RSMS[1:0]

RECEIVER

MONITOR MODE

GAIN (dB)

RECEIVER SENSITIVITY

(MAX CABLE LOSS

ALLOWED) (dB)

0 00

0

12

0 01

0

20

0 10

0

30

0

11

0

36 for T1; 43 for E1

Table 10-24. Receiver Sensitivity Selection with Monitor Mode Enabled

RMONEN

RSMS[1:0]

RECEIVER

MONITOR MODE

GAIN (dB)

RECEIVER SENSITIVITY

(MAX CABLE LOSS

ALLOWED) (dB)

1 00

14

30

1 01

20

22.5

1 10

26

17.5

1 11

32

12
