DS26519 16-Port T1/E1/J1 Transceiver
59 of 310
Table 9-12. ESF Framing Mode
FRAME
NUMBER
FRAMING FDL CRC SIGNALING
1 √
2 CRC1
3 √
4 0
5
√
6 CRC2 √
7 √
8 0
9
√
10 CRC3
11 √
12 √
13 √
14 CRC4
15 √
16 0
17
√ √
18 CRC5
19 √
20 1
21
√
22 CRC6
23 √
24 1 √
Table 9-13. SLC-96 Framing
FRAME NUMBER Ft Fs SIGNALING
1 1
2 0
3 0
4 0
5 1
6 1 A
7 0
8 1
9 1
10 1
11 0
12 0 B
13 1
14 0
15 0
16 0
17 1
18 1 C
19 0
20 1
21 1
22 1
23 0
24
C1 (Concentrator Bit) D
25 1
26
C2 (Concentrator Bit)
27 0
