DS26519 16-Port T1/E1/J1 Transceiver
218 of 310
Register Name:
TS1 to TS16
Register Description:
Transmit-Signaling Registers
Register Address:
140h to 14Fh + (200h x (n - 1)) + (2000h x [(n - 1) / 8]): where n = 1 to 16
T1 Mode:
(MSB)
(LSB)
Bit
# 7 6 5 4 3 2 1 0
Name CH1-A
CH1-B
CH1-C
CH1-D
CH13-A
CH13-B
CH13-C
CH13-D
TS1
CH2-A
CH2-B
CH2-C
CH2-D
CH14-A
CH14-B
CH14-C
CH14-D
TS2
CH3-A
CH3-B
CH3-C
CH3-D
CH15-A
CH15-B
CH15-C
CH15-D
TS3
CH4-A
CH4-B
CH4-C
CH4-D
CH16-A
CH16-B
CH16-C
CH16-D
TS4
CH5-A
CH5-B
CH5-C
CH5-D
CH17-A
CH17-B
CH17-C
CH17-D
TS5
CH6-A
CH6-B
CH6-C
CH6-D
CH18-A
CH18-B
CH18-C
CH18-D
TS6
CH7-A
CH7-B
CH7-C
CH7-D
CH19-A
CH19-B
CH19-C
CH19-D
TS7
CH8-A
CH8-B
CH8-C
CH8-D
CH20-A
CH20-B
CH20-C
CH20-D
TS8
CH9-A
CH9-B
CH9-C
CH9-D
CH21-A
CH21-B
CH21-C
CH21-D
TS9
CH10-A
CH10-B
CH10-C CH10-D CH22-A CH22-B CH22-C CH22-D TS10
CH11-A
CH11-B
CH11-C CH11-D CH23-A CH23-B CH23-C CH23-D TS11
CH12-A
CH12-B
CH12-C CH12-D CH24-A CH24-B CH24-C CH24-D TS12
Note: In D4 framing mode, the C and D bits are not used.
E1 Mode:
(MSB)
(LSB)
Bit
# 7 6 5 4 3 2 1 0
Name
0 0 0 0 X Y X X
TS1
CH1-A CH1-B CH1-C CH1-D CH16-A
CH16-B
CH16-C
CH16-D
TS2
CH2-A CH2-B CH2-C CH2-D CH17-A
CH17-B
CH17-C
CH17-D
TS3
CH3-A CH3-B CH3-C CH3-D CH18-A
CH18-B
CH18-C
CH18-D
TS4
CH4-A CH4-B CH4-C CH4-D CH19-A
CH19-B
CH19-C
CH19-D
TS5
CH5-A CH5-B CH5-C CH5-D CH20-A
CH20-B
CH20-C
CH20-D
TS6
CH6-A CH6-B CH6-C CH6-D CH21-A
CH21-B
CH21-C
CH21-D
TS7
CH7-A CH7-B CH7-C CH7-D CH22-A
CH22-B
CH22-C
CH22-D
TS8
CH8-A CH8-B CH8-C CH8-D CH23-A
CH23-B
CH23-C
CH23-D
TS9
CH9-A CH9-B CH9-C CH9-D CH24-A
CH24-B
CH24-C
CH24-D
TS10
CH10-A CH10-B CH10-C CH10-D CH25-A CH25-B CH25-C CH25-D TS11
CH11-A CH11-B CH11-C CH11-D CH26-A CH26-B CH26-C CH26-D TS12
CH12-A CH12-B CH12-C CH12-D CH27-A CH27-B CH27-C CH27-D TS13
CH13-A CH13-B CH13-C CH13-D CH28-A CH28-B CH28-C CH28-D TS14
CH14-A CH14-B CH14-C CH14-D CH29-A CH29-B CH29-C CH29-D TS15
CH15-A CH15-B CH15-C CH15-D CH30-A CH30-B CH30-C CH30-D TS16
