1 OUTLINE
S1C33210 PRODUCT PART
EPSON
A-5
1.3.2 Pin Functions
Table 1.3.1 List of Pins for Power Supply System
Pin name
Pin No.
I/O
Pull-up
Function
QFP15-128
V
DD
8, 27, 47, 74, 93, 111
–
–
Power supply (+)
V
SS
3, 22, 39, 54, 67, 90,
102, 104
–
(104
Pull-
down)
Power supply (-); GND
AV
DD
30
–
–
Analog system power supply (+); AV
DD
= V
DD
Table 1.3.2 List of Pins for External Bus Interface Signals
Pin name
Pin No.
I/O
Pull-up
Function
QFP15-128
A0
#BSL
55
O
–
A0:
Address bus (A0) when SBUSST(D3/0x4812E) = "0" (default)
#BSL:
Bus strobe (low byte) signal when SBUSST(D3/0x4812E) = "1"
A[23:1]
56-58, 63-66, 69, 70, 72,
75, 78, 81, 84, 85, 87-89,
91, 73, 76, 79, 82
O
–
Address bus (A1 to A23)
D[15:0]
7, 10, 12, 14, 16, 18, 25, 26,
36-38, 40-42, 45, 46
I/O
–
Data bus (D0 to D15)
#CE10EX
#CE9&10EX
34
O
–
Area 10 chip enable for external memory
*
When CEFUNC[1:0] = "1x", this pin outputs #CE9+#CE10EX signal.
#CE9
#CE17
#CE17&18
48
O
–
#CE9:
Area 9 chip enable when CEFUNC[1:0](D[A:9])/0x48130) = "00"
(default)
#CE17:
Area 17 chip enable when CEFUNC[1:0](D[A:9])/0x48130) = "01"
*
When CEFUNC[1:0] = "1x", this pin outputs #CE17+#CE18 signal.
#CE8
#RAS1
#CE14
#RAS3
53
O
–
#CE8:
Area 8 chip enable when CEFUNC[1:0](D[A:9])/0x48130) = "00"
and A8DRA(D8/0x48128) = "0" (default)
#RAS1:
Area 8 DRAM row strobe when CEFUNC[1:0](D[A:9])/0x48130) =
"00" and A8DRA(D8/0x48128) = "1"
#CE14:
Area 14 chip enable when CEFUNC[1:0](D[A:9])/0x48130) = "01"
or "1x" and A14DRA(D8/0x48122) = "0"
#RAS3:
Area 14 DRAM row strobe when CEFUNC[1:0](D[A:9])/0x48130)
= "01"or "1x" and A14DRA(D8/0x48122) = "1"
#CE7
#RAS0
#CE13
#RAS2
49
O
–
#CE7:
Area 7 chip enable when CEFUNC[1:0](D[A:9])/0x48130) = "00"
and A7DRA(D7/0x48128) = "0" (default)
#RAS0:
Area 7 DRAM row strobe when CEFUNC[1:0](D[A:9])/0x48130) =
"00" and A7DRA(D7/0x48128) = "1"
#CE13:
Area 13 chip enable when CEFUNC[1:0](D[A:9])/0x48130) = "01"
or "1x" and A13DRA(D7/0x48122) = "0"
#RAS2:
Area 13 DRAM row strobe when CEFUNC[1:0](D[A:9])/0x48130)
= "01" or "1x" and A13DRA(D7/0x48122) = "1"
#CE6
#CE7&8
52
O
–
Area 6 chip enable
*
When CEFUNC[1:0] = "1x", this pin outputs #CE7+#CE8 signal.
#CE5
#CE15
#CE15&16
71
O
–
#CE5:
Area 5 chip enable when CEFUNC[1:0](D[A:9])/0x48130) = "00"
(default)
#CE15:
Area 15 chip enable when CEFUNC[1:0](D[A:9])/0x48130) = "01"
*
When CEFUNC[1:0] = "1x", this pin outputs #CE15+#CE16 signal.
