4-132

TNC 406/TNC 306

14 Electrode changer

2/97

14.2.2 PLC module "REPLACE OLD TOOL"

Push

SPIREG - 1

To Stack

Module:

POC. REG.

TOOL RACK

POS. REACHED

Module:

PLC. POS.

Z DOWN

Tool Unclamped

and set

SPRIEG to 0

Module:

Z UP

PLC. POS.

TOOL CLAMP

TOOL CLAMP

END

Return Current Electrode to Original Rack Position

Yes

No

?
