3/99
TNC 416/TNC 406/TNC 306 Mounting dimensions 3–85
Adapter RS–232–C and RS-422
78±0.2
3.071±.008"
60+1
2.36+.04"
5
.2"
21+0.5
.83"+.02"
78±0.2
3.071±.008" 7
.28"
M4
38 1.5"
92
3.62"
57
2.24"
M 5
3
.1
2"
R 40
R 1
.57"
