Ultra1500 Connector Data

2-17

Figure 2.15
Sequencing and Phasing of the Hall Signals

Figure 2.16
Sequencing and Phasing of the Hall Signals (60° Hall Offset Example)

Figure 2.17 shows the proper phasing of TTL A/B encoder signals when
positive current is applied.

Figure 2.17
Phasing of TTL A/B Encoder Signals
