Publication 2092-UM001D-EN-P — July 2005

Interconnect and Cable Diagrams

B-11

Generic Linear Motor
Connections

Figure B.10 shows the recommended feedback wiring for a 3rd party linear
motor with an incremental AQB encoder and Hall signals.

Figure B.10
Ultra1500 and Generic Linear Motor Feedback Wiring Diagram

ULTRA1500

EPWR

ECOM

A+

NOTES:

1.

IF THE MOTOR DOES NOT HAVE A THERMISTOR OR THERMOSTAT, THE THERMOSTAT INPUT OF THE ULTRA1500 FOUND ON PIN 2 OF CN2
SHOULD BE LEFT DISCONNECTED.

MOTOR

FEEDBACK

CONNECTOR

A-

B+

B-

20

1

3

4

5

6

CN2

+5V

COM

A+

A-

B+

B-

SHIELD

SHIELD

I+

I-

7

8

I+

I-

S1+

10

HALL A+

S2+

14

HALL B+

S3+

16

HALL C+

TS

2

TS+

TS-

1
