Anorad linear motor connections – Rockwell Automation 2092-DAx Ultra1500 User Manual User Manual
Page 154
Publication 2092-UM001D-EN-P — July 2005
B-10
Interconnect and Cable Diagrams
Anorad Linear Motor
Connections
Figure B.9 shows the recommended feedback wiring for an Anorad linear
motor.
Figure B.9
Ultra1500 and Anorad Linear Motor Feedback Wiring Diagram
ULTRA1500
EPWR
ECOM
A+
ANORAD
LINEAR
MOTOR
FEEDBACK
CONNECTOR
A-
B+
B-
20
1
3
4
5
6
CN2
+5V
COM
A+
A-
B+
B-
SHIELD
SHIELD
I+
I-
7
8
I+
I-
S1+
10
14
HALL A
HALL B
S2+
16
HALL C
S3+
THERM+
THERM-
TS
2
