1 - installing your ultra1500, Chapter objectives, Chapter 1 – Rockwell Automation 2092-DAx Ultra1500 User Manual User Manual
Page 13: Installing your ultra1500, Chapter objectives -1
1
Publication 2092-UM001D-EN-P — July 2005
Chapter
1
Installing Your Ultra1500
Chapter Objectives
This chapter provides system installation guidelines and procedures for
mounting your Ultra1500. This chapter covers the following topics:
• Complying with European Union (CE) and TTMRA (C-Tick) Directives
• Ultra1500 System Overview
• Ultra1500 Servo System Overviews Before Mounting Your System
• HF Bonding Your System
• Planning Your Panel Layout
• Mounting Your Ultra1500 Drive
ATTENTION
!
The following information is a guideline for proper
installation. The National Electrical Code and any other
governing regional or local codes overrule this information.
The Allen-Bradley Company cannot assume responsibility
for the compliance or the noncompliance with any code,
national, local or otherwise, for the proper installation of
this system or associated equipment. If you ignore codes
during installation, hazard of personal injury and/or
equipment damage exists.
