DS4830 User’s Guide
73
QTDATA Register map when RW_LST = 0 (in the QTCN Register)
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Name
-
LOW or HIGH THRESHOLD
-
Reset
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
Access
r
r
r
r
r
r
rw
rw
rw
rw
rw
rw
rw
rw
rw
rw
BIT
NAME
DESCRIPTION
15:10
-
Reserved. T
he user should write these bits to ‘0’.
9:2
QTDATA[9:2]
a. Low Threshold Configuration (When the LTHT bit in the QTCN register
is set to ‘0’)
The QTDATA register selects low threshold register addressed by QTIDX[3:0] bits in the
QTCN register for read and write operation. The low threshold registers are 10-bit wide
but only bits QTDATA [9:2] are used in comparison and the upper QTDATA [15:10] bits
are ignored and return 0. The user should write 0 at the QTDATA [1:0] bits.
b. High Threshold Configuration (When the LTHT bit in the QTCN register
is set to ‘1’)
The QTDATA selects high threshold register addressed by QTIDX[3:0] bits in the QTCN
register for read and write operation. The high threshold registers are 10-bit wide but only
bits QTDATA [9:2] are used in comparison and upper QTDATA [15:10] bits are ignored
and return 0. The user should write 0 at the QTDATA [1:0] bits.
1:0
-
Reserved. The user should write 00b to these bits.
QTDATA Register map when RW_LST = 1 (in the QTCN Register)
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Name
-
-
-
-
-
-
-
-
-
-
-
DIFF
CHSEL[3:0]
Reset
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
Access
r
r
r
r
r
r
r
r
r
r
r
rw
rw
rw
rw
rw
BIT
NAME
DESCRIPTION
15:5
-
Reserved. The user should write 0 to these bits.
4
DIFF
Mode Selection (DIFF
):
This bit selects the Quick trip input channel source either as
single ended
or differential mode. When this bit is set to ‘0’, quick trip channel (addressed
by CHSEL[3:0] is select as “Single Ended” input. When this bit is set to ‘1’, quick trip
channel (addressed by CHSEL[3:0] is select as “Differential Mode” input. Refer below
table for various quick trip input channel configuration in Single Ended as well as
differential mode.
3:0
CHSEL
[3:0]
QT Channel Select (CHSEL
[3:0]):
These bits select the Quick trip input channel source
for the quick trip list configuration.
CHSEL[3:0]
DIFF = 0
Channel Selected
Single Ended
DIFF = 1
Channel Selected
Differential Mode
0000
ADC-S0
ADC-D0P
– ADC-D0N
0001
ADC-S1
ADC-D1P
– ADC-D1N
0010
ADC-S2
ADC-D2P
– ADC-D2N
0011
ADC-S3
ADC-D3P
– ADC-D3N
0100
ADC-S4
ADC-D4P
– ADC-D4N
0101
ADC-S5
ADC-D5P
– ADC-D5N
0110
ADC-S6
ADC-D6P
– ADC-D6N
0111
ADC-S7
ADC-D7P
– ADC-D7N
1000
ADC-S8
NOT VALID
1001
ADC-S9
NOT VALID
1010
ADC-S10
NOT VALID
1011
ADC-S11
NOT VALID
1100
ADC-S12
NOT VALID
1101
ADC-S13
NOT VALID
1110
ADC-S14
NOT VALID
1111
ADC-S15
NOT VALID
