DS4830 User’s Guide
25
3.1 Accumulator Pointer Register (AP, 8h[0h])
Initialization: This register is cleared to 00h on all forms of reset.
Access: Unrestricted direct read/write access.
Bit Name Function
7:4 Reserved Reserved. All reads return 0.
3:0 AP[3:0]
Active Accumulator Select. These bits select which of the 16 accumulator registers are used for arithmetic and logical
operations. If the APC register has been set to perform automatic increment/decrement of the active accumulator, this setting
will be automatically changed after each arithmetic or logical operation. I
f a ‘MOVE AP, Acc’ instruction is executed, any enabled
AP inc/dec/modulo control will take precedence over the transfer of Acc data into AP.
3.2 Accumulator Pointer Control Register (APC, 8h[1h])
Initialization: This register is cleared to 00h on all forms of reset.
Access: Unrestricted direct read/write access.
Bit Name Function
7 CLR
AP Clear. Writing this bit to 1 clears the accumulator pointer AP to 0. Once set, this bit will automatically be reset to 0 by
hardware. If a ‘MOVE APC, Acc’ instruction is executed requesting that AP be set to 0 (i.e., CLR = 1), the AP clear function
overrides any enabled inc/dec/modulo control. All reads from this bit return 0.
6 IDS
Increment/Decrement Select. If this bit is set to 0, the accumulator pointer AP is incremented following each arithmetic or logical
operation according to MOD[2:0]. If this bit is set to 1, the accumulator pointer AP is decremented following each arithmetic or
logical operation according to MOD[2:0]. If MOD[2:0] is set to 000, the setting of this bit is ignored.
5:3 Reserved Reserved. All reads return 0.
2:0 MOD[2:0]
Accumulator Pointer Auto Increment/Decrement Modulus. If these bits are set to a nonzero value, the accumulator pointer
(AP[3:0]) will be automatically incremented or decremented following each arithmetic or logical operation. The mode for the
auto-increment/ decrement is determined as follows:
MOD[2:0] AUTO INCREMENT/DECREMENT MODE
000 No auto-increment/decrement (default)
001 Increment/decrement AP[0] modulo 2
010 Increment/decrement AP[1:0] modulo 4
011 Increment/decrement AP[2:0] modulo 8
100 Increment/decrement AP modulo 16
101 to 111 Reserved (modulo 16 when set)
3.3 Processor Status Flags Register (PSF, 8h[4h])
Initialization: This register is cleared to 80h on all forms of reset.
Access: Bit 7 (Z), bit 6 (S), and bit 2 (OV) are read only. Bits [4:3] (GPF[1:0]), bit 1 (C), and bit 0 (E) are unrestricted
read/write.
Bit Name Function
7 Z
Zero Flag. The value of this bit flag equals 1 whenever the active accumulator is equal to zero. This bit equals 0 if the active
accumulator is not equal to 0.
6 S Sign Flag. This bit flag mirrors the current value of the high bit of the active accumulator (Acc.15).
5 Reserved Reserved. All reads return 0.
4:3 GPF[1:0] General-Purpose Flags. These general-purpose flag bits are provided for user software control.
2 OV
Overflow Flag. This flag is set to 1 if there is a carry out of bit 14 but not out of bit 15, or a carry out of bit 15 but not out of bit 14
from the last arithmetic operation, otherwise, the OV flag remains as 0. OV indicates a negative number resulted as the sum of
two positive operands, or a positive sum resulted from two negative operands.
1 C
Carry Flag. This bit flag is set to 1 whenever an add or subtract operation (ADD, ADDC, SUB, SUBB) returns a carry or borrow.
This bit flag is cleared to 0 whenever an add or subtract operation does not return a carry or borrow. Many other instructions
potentially affect the carry bit. Reference the instruction set documentation for details.
0 E
Equals Flag. This bit flag is set to 1 whenever a compare operation (CMP) returns an equal result. If a CMP operation returns not
equal, this bit is cleared.
3.4 Interrupt and Control Register (IC, 8h[5h])
Initialization: This register is cleared to 00h on all forms of reset.
Access: Unrestricted direct read/write access.
Bit Name Function
7:2 Reserved Reserved. All reads return 0.
1 INS
Interrupt In Service. The INS is set by hardware automatically when an interrupt is acknowledged. No further interrupts occur as
long as the INS remains set. The interrupt service routine can clear the INS bit to allow interrupt nesting. Otherwise, the INS bit is
cleared by hardware upon execution of an RETI or POPI instruction.
0 IGE
Interrupt Global Enable. If this bit is set to 1, interrupts are globally enabled, but still must be locally enabled to occur. If this bit is
set to 0, all interrupts are disabled.
